- Page 1 RHT-Air WIRELESS DEVICE TEMPERATURE, RELATIVE HUMIDITY AND DEW POINT INSTRUCTIONS MANUAL V2.0x A NOVUS AUTOMATION 1/10...
-
Page 2: Specifications
Antenna measurement: 105 mm. Sensor measurement: 37,2 mm. Weight 171 grams / 40 grams (cable). Configuration DigiConfig – Configuration software software Windows. CE, FCC, ANATEL (00172-13-07089). Certifications Contains FCC ID: 2AXVWBAIRR-NOVUSAIR. EMC: EN61326-1:2006 CISPR11/EN55011, Electromagnetic EN61000-4-2, EN61000-4-3, EN61000-4-4, compatibility EN61000-4-6, EN61000-4-8... -
Page 3: Mechanical Installation
2.1 ACCURACY OF MEASUREMENTS AND OPERATIONAL LIMITS OF SENSORS Figure 3 – Accuracy of the humidity and temperature measurement MECHANICAL INSTALLATION RHT-Air was designed to be attached to walls. By removing the device cover, users will have access to two molding holes of the base, as shown in Figure 4. - Page 4 5.2.1 REPLACING THE INTERNAL BATTERY It is possible to check the battery charge through register “29”. A fully charged battery typically has a power above 3.6 V. As you use the RHT-Air, the power of the battery will gradually decrease. It is recommended to periodically check the value of the “29”...
-
Page 5: Configuration & Operation
6 CONFIGURATION / OPERATION Display screens only for measured values on the device: DigiConfig is a Windows software used for configuring RHT-Air. To install it, please run the file “DigiConfigSetup.exe”, available in our website www.novusautomation.com. DigiConfig comes with an unabridged help tutorial, containing all the necessary information for you to use it. - Page 6 REGISTER 16 – POWER LEVEL CHANNEL OPERATION FREQUENCY According to the variations presented in the table below, the power level can be 2405 MHz adjusted as needed. The higher the power set, the greater the range and the 2410 MHz greater the consumption.
- Page 7 REGISTER 29 – BATTERY POWER responds through the address it was configured for in this register according to the communication parameters of the Modbus network on which it was It has the value of measuring the voltage level of the battery in engineering installed.
-
Page 8: Special Care
HOLDING REGISTERS TABLE The specified addresses correspond to lower-level physical addresses, as zero (0) corresponds to the PLC 40001 address. The columns reserved for Minimum and Maximum contain a range of valid values for each parameter. The column reserved for R/W indicates whether the parameters are meant for reading and writing (R/W) or reading only (R). ADDRESS DESCRIPTION MINIMUM... -
Page 9: Troubleshooting
ANATEL This device is homologated by ANATEL, in accordance with the procedures regulated by Resolution 242/2000, and meets the technical requirements applied. This equipment is not subject to the protection from harmful interference and may not cause interference with duly authorized systems. -
Page 10: Warranty
11 WARRANTY Warranty conditions available website www.novusautomation.com/warranty. NOVUS AUTOMATION 10/10...
