1.
Test requirements
Massage timer
Massage head
zeroG button
memory1 button
Head up
Head down
FLAT
RF392A
Test Instruction of RF392C
Head up
Head down
FLAT
foot up
foot down
RF392C
Head up
Head down
memory1 button
FLAT
1 / 5
Massage foot
foot up
UBB
foot down
memory3 button
memory2 button
RF392B
foot up
foot down
memory3 button
memory2 button
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ergomotion RF392C
Summary of Contents for Ergomotion RF392C
- Page 1 Test Instruction of RF392C Test requirements Massage timer Massage head Massage foot Head up foot up zeroG button Head down foot down memory3 button memory1 button memory2 button FLAT RF392C Head up foot up foot up Head up Head down foot down Head down...
- Page 2 Test item 2.1 pairing test 1. Double‐click the pairing button on the control box, the pairing indicator lights, and the control box enters pairing mode; 2. Press and hold the pairing button on the remote (the white button under the battery cover on the back) until the pairing indicator on the control box goes off, then the pairing is successful. Operate the remote to verify, if the pairing is unsuccessful, repeat steps 1‐2); Software version test Read the software version information of the remote through the software of the host computer‐> SW INFO‐>: 11801‐101 2.2 Massage head test Click massage head button, the head massage motor switches the massage intensity, and the massage intensity cycles between 0‐1‐3‐6; ...
- Page 3 foot up te rate the Foot t up button o on the remote e control, the e foot actuato or will move o out and stop after relea asing; foot dow wn test rate the Foo t down butto on on the re emote contro ol, the foot a ctuator will m move in and stop afte r releasing; ...
- Page 4 Press and hold zeroG+flat for 5s, the control box will restore memoryIII position to factory setting; 2.17 FLAT test Click FLAT butoon, actuator will move in to lowest position; FCC Warning ： Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two ...
- Page 5 FCC ID: WKZCU358 IC: 20840-CU358 FCC ID: 2AK23RF392AC IC: 22406-RF392AC 5 / 5...
