Am AS133 Instructions

AS133/AS134/AS135/AS136 Instructions
A - Bowsprit
B - Mast
C - Main Sail
D - Boom
E - First Jib
F - Second Jib
Be sure to follow the directions and
not unwind any lines until ready to
connect, otherwise they can become
tangled.
1. Remove boat and sails from the box.
2. Unwrap sails, and place mast into mast step just in front
of cabin.
3. Place bowsprit under 2 brass plates, on front of boat. Connect
line on bottom of bowsprit to eye hook on the bottom side
of the bow. Connect lines on left and right side of the
bowsprit to the eye hooks on the left and right side of
the boat.
4. Connect front corner of First Jib to the 1st eye hook on
bowsprit. Connect aft corner to 1st eye hook on deck
(next to mast).
C
D
B
F
5. Connect front corner of Second Jib to 2nd eye hook on
bowsprit. Connect aft corner to the 3rd eye hook on deck
(next to mast).
6. To rig mainsail, hook end of boom to eye hook on back
deck. Locate end of main halyard (line connected in a 'Z'
at top of main sail) and begin working the line through the
blocks. Hook end of line to 2nd eye hook right next to mast.
Pull up on adjustors to tighten lines.
