Getting To Know Your Subwoofer
LEFT
–
A
–
RIGHT
G
100–120V | 220–240V
H
+
B
+
C
D
0
E
180
F
J
I
AC 100–120V -60Hz 3.3A(MAX)
AC 220–240V -50Hz 1.65A(MAX)
Legend
HIGH LEVEL INPUT LEFT/RIGHT
A
(SPEAKER LEVEL IN)
B
VOLUME UP/DOWN KNOB
C
LOW PASS FILTER UP/DOWN KNOB
D
LFE IN
E
PHASE SWITCH (0 = DEFAULT)
F
STATUS LED
AC POWER VOLTAGE SELECTOR
G
SWITCH
H
POWER ON/OFF SWITCH
FUSE ~100-120V T6.3AL/250V
I
~220240V T4AL/250V
J
AC POWER INLET
EN
7
