  • Page 1 DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI ENGLISH OWNER’S MANUAL HELP LINE Number ; 0870 100 2525 With queries, please quote the page number, reference number and model number. Set-Top BOX Digital Terrestrial Receiver DSD-800M...

  • Page 2: Safety Information

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI SAFETY INFORMATION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, CAUTION: To reduce the risk of fire and or near a swimming pool and the like.
  • Page 3 DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI SAFETY INFORMATION This STB has been manufactured to satisfy international safety standards. safety characteristics as the original parts. Use of replacements specified by the video product manufacturer can prevent fire, electric shock, or other Please read the following recommended safety precautions hazards.

  • Page 4: Table Of Contents

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI CONTENTS SAFETY INFORMATION SYSTEM SET-UP System setup menu OSD Language TV System INTRODUCTION- About the STB Region and Time Front panel Timer Setting Rear panel OSD Setting Remote control Parental Lock SYSTEM CONNECTION General about connections Tools Connecting to the TV aerial...

  • Page 5: Introduction- About The Stb

    DSD-800M_UK_2007 2007.10.4 2:15 PM ˘ mac001 1200DPI 90LPI INTRODUCTION -About the STB Front panel Remote sensor Power indicator Rear panel TV aerial Coaxial Digital Audio AC Mains RF Loop through for an external Device TV Scart for connection to the TV Remote control Œ...
  • Page 6 DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI INTRODUCTION-About the STB Using Remote control • Remove the battery compartment cover. • Load two AAA (UM-4 or R03) batteries into the battery compartment. • Make sure that the batteries have been inserted with the correct polarities matching to the symbols +, - marked in the battery compartment.

  • Page 7: System Connection

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI SYSTEM CONNECTION General about connections Connecting to the TV aerial There are many different types of equipments that you can You can connect the STB to the following type of aerials: connect to the STB. Œ...

  • Page 8: Connecting To The Tv With Scart

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI SYSTEM CONNECTION Connecting to the TV with SCART Connecting a Amplifier/Receiver system • Remove the aerial lead from your TV and connect this to You can connect an RCA/Cinch single cable from the the TV AERIAL input socket on the STB.

  • Page 9: Getting Started

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI GETTING STARTED Easy Install Channel scan Press the "MENU" button to enter main menu. If you use the STB for the first time, the "Easy Install" menu appears. Select "Installation", press the "OK" button to enter Installation menu.

  • Page 10: Operation

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI OPERATION Changing Channels There are four ways of channel selection - stepping through Accessing the Electronic Program Guide (EPG) the channel list, selection by number, from the on-screen Accessing the EPG of all channels: channel list, and using the electronic programme guide (EPG).

  • Page 11: Channel

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI CHANNEL Channel list menu Favour: Press the "MENU" button to enter the main menu, select "Channel" and press the "OK" button to enter • In "Edit Channel" menu, press numeric button "1" Channel menu.

  • Page 12: Find

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI CHANNEL Move In channel list menu, press numeric button "4" , the • Press the "EXIT" button or Highlight "ESC" and press selected channel will be marked by a symbol " ". the "OK"...

  • Page 13: Delete All Favourites

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ mac001 1200DPI 90LPI CHANNEL Delete All Favourites Group Rename Use this menu to delete all favourite channels. Use this menu to change the group name. In the Channel menu, select "Delete All Favourites", In Channel menu, select "Group Rename", press the press the "OK"...

  • Page 14: System Set-Up

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 10 mac001 1200DPI 90LPI SYSTEM SET-UP System setup menu TV System System setup menu allows us to set OSD Language, TV This menu allows us to set the Aspect Ratio, Video Output System, Region and Time, Timer Setting, OSD Setting and and LCN Mode.

  • Page 15: Region And Time

    DSD-800M_UK_2007 2007.10.2 5:58 PM ˘ ` 11 mac001 1200DPI 90LPI SYSTEM SET-UP Region and Time Timer Setting This menu allows you to set the region and time. Region : This menu is used for changing the region setting. This menu allows you to set the GMT Usage : This menu is used for open the usage of program timer and sleep timer.

  • Page 16: Osd Setting

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 12 mac001 1200DPI 90LPI SYSTEM SET-UP OSD Setting Parental Lock This menu allows you to set Subtitle Display, OSD This menu allows you to password protect the installation Transparency, OSD Style and load default OSD setting. menu and channel, and change the password.

  • Page 17: Tools

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 13 mac001 1200DPI 90LPI Tools Tools main menu Game Press the "MENU" button to enter main menu. This menu allows you to play games on this STB. Select "Tools", press the "OK" button to enter tools In "Tools"...

  • Page 18: Software Upgrade

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 14 mac001 1200DPI 90LPI Tools Software Upgrade We offer the functions for user to upgrade software version by Upgrade by RS-232 RS-232 Interface via Scart jack or by air. Connect master STB to slave receiver via serial Enter "Tools"...

  • Page 19: Troubleshooting

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 15 mac001 1200DPI 90LPI TROUBLESHOOTING In some region, the digital terrestrial signal may be weak. So it is advisable to use an antenna with a signal booster for watching weak signal channels. Problem Possible cause What to do Standby light not lit.

  • Page 20: Specifications

    DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 16 mac001 1200DPI 90LPI SPECIFICATIONS TUNER & CHANNEL CONNECTION RF INPUT CONNECTOR x1 (IEC-TYPE, MAIN POWER CABLE FIXED TYPE IEC169-2, FEMALE) TUNER ANTENNA INPUT x 1, RF RF OUTPUT CONNECTOR x1 OUTPUT x1 (IEC-TYPE, IEC169-2, MALE SCART TV INPUT x 1 (LOOPTHROUGH))
  • Page 21 DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 17 mac001 1200DPI 90LPI...
  • Page 22 DSD-800M_UK_2007 2007.10.2 5:54 PM ˘ ` 18 mac001 1200DPI 90LPI...
  • Page 23 ˘ ` 19 mac001 1200DPI 90LPI Connection Quick Guide DSD-800M To connect your STB to your TV If you want to record digital channels on your VCR/DVR Use a scart cable to connect the set top box to your TV.
