Getting Started
Congratulations on landing your new 360fly 4K camera.
This powerful camera and its apps make you part of an emerging community of visual
storytellers and explorers, one that is fundamentally changing the way we experience and capture
the world. Join them now and begin sharing your best 360° 4K videos, ideas, and
inspiration at www.360fly.com.
Charging the Battery:
To charge your camera, insert the USB cable into a USB outlet adapter rated at 1.5A to 2.1A
(most tablet charger adapters) and plug it into the 360fly 4K Power Cradle.
Next, simply place the camera on the charger base. For best results, charge your camera while
it's powered off.
While your camera is charging, its LED indicator will flash green. When fully charged, the
camera LED will remain solid green. It is recommended you charge your camera for at least 30
minutes prior to its first use.
When your camera battery is low, the LED will display a light purple color. Be sure to charge
your camera before using it when the LED is light purple.
Powering Up:
Remove the camera from its Power Cradle and turn it on by holding the OnePush button down
for four seconds. The triangular OnePush button is surrounded by the LED indicator and located
on the side of the camera. When powering up, the camera will vibrate three times and the LED
will flash blue. After completing the power-up sequence, the LED will display a solid blue color,
indicating that your camera is on and ready to fly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4K camera and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for 360fly 4K camera

  • Page 1 To charge your camera, insert the USB cable into a USB outlet adapter rated at 1.5A to 2.1A (most tablet charger adapters) and plug it into the 360fly 4K Power Cradle. Next, simply place the camera on the charger base. For best results, charge your camera while it’s powered off.
  • Page 2: Camera Care And Storage

    The camera will vibrate four times to indicate that it is powering down. Camera Care and Storage: A clean lens means clearer footage. Your 360fly 4K camera lens can be cleaned using a soft cloth. Lens solution, water, or isopropyl alcohol can be added for additional cleaning.
  • Page 7 Create Your 360fly Account: On the first app launch, you’ll also be prompted to build your 360fly.com profile. You can select the “Sign In” option to activate via your existing social media account, or you can choose to “Sign Up” for a unique 360fly.com account by entering a new username, email address, and setting a password for your new profile.
  • Page 11 Wi-Fi connection to your camera. When prompted, accept the Bluetooth pairing request within the app to confirm your connection between your Apple device and your 360fly camera. Note: A Wi-Fi connection is required to view your camera’s live feed and stored content. Check...
  • Page 16 Once the power up sequence is completed, your 360fly 4K will automatically enter pairing mode with your mobile device. For best results, place your phone about three inches away from your camera in order to get a good strong signal. Once the devices are paired, it’s time to give your...
  • Page 19 In order to get full functionality from your 360fly 4K, you need to connect your device to your camera via Wi-Fi. To complete this final step, exit your app and access the settings menu on your iOS device. Select Wi-Fi and search for your camera under the name that you have just...
  • Page 21 The User Generated section lets you share your 360° vision with the entire 360fly family and anyone with the 360fly app. Be sure to check in often—and remember to tag your best edits shared across social media using #360fly and #MissNothing. At the bottom of the homepage...
  • Page 23: Camera Home Screen

    360fly camera. You can also choose to make any of your videos public and share your experiences with friends and other 360fly users. To make changes or edits to your account, just tap the edit profile option at the top of the screen.
  • Page 25: Recording Video

    Recording Video Recording 360° videos with the 360fly app is quick and easy. Simply tap the white record button to start capturing. The center of the capture button will turn red and your camera will simultaneously vibrate while its LED turns from blue to red.
  • Page 26 Recording Without the App If you don’t have access to the 360fly app on your mobile device, you can record videos directly on your camera. Simply press the OnePush button on your camera to launch a 360° recording. Your camera will vibrate and the LED will turn from blue to solid red, indicating that your camera is now recording.
  • Page 27: Time-Lapse Mode

    “Live View” display on your screen. Change the interval between frame captures by adjusting the scroll bar to your desired setting. Your 360fly 4K offers settings for 0.5, 1, 2, 5, 10, 30, or 60 seconds between frames when in Time-Lapse mode. After selecting your desired speed, press the Time-Lapse icon again to confirm.
  • Page 28 60 FPS Mode Your 360fly 4K camera allows you to record videos at 60 frames per second with a resolution of 1728x1728 pixels. Perfect for extreme action sequences, this recording option is ideal for creating slow-motion effects when editing your videos and creating action clips.
  • Page 29: Still Image Capture

    Still Image Capture Your 360fly 4K doubles as a still image action camera, allowing you to capture .jpeg photos at an effective resolution of 3456x3456 pixels. Your 360° images can be viewed within the mobile application or via the 360fly desktop Director app on PC or Mac.
  • Page 30 Camera Burst mode at the top of the live view display on your screen. Pre-set your frame capture intervals by adjusting the slider to your desired setting. The 360fly 4K offers settings for 3, 5, or 8 captures per second within burst mode. After selecting your desired speed, press the Camera Burst icon to confirm your setting.
  • Page 32: Video Playback

    Tapping a video thumbnail image within your camera’s library will automatically launch the 360fly player. Once the video uploads, you can pan the angle of view by swiping across the screen. You can also pan using your device’s built-in gyroscope function by turning your phone in the desired orientation.
  • Page 33: General Camera Settings

    Virtual Reality Goggle Playback 360fly 4K footage is designed to work seamlessly with most Google Cardboard VR viewers with just the touch of a button. To watch your footage using a Google Cardboard viewer, just tap the VR viewer icon located at the top-right while you’re in the video player screen.
  • Page 34: Image Tuning

    Image Tuning The default settings of the 360fly 4K camera are optimized to deliver the highest quality output within a wide range of environments and lighting conditions. To get the most out of your videos and images, the 360fly 4K offers advanced options that will allow you to fine-tune your camera’s settings.
  • Page 35 If you haven’t already, you will need to download your desired file from your camera library into your smart device’s memory in order to access the 360fly app editing and sharing features. You can access your camera’s library by selecting the “On My Camera” icon to view your camera’s storage library.
  • Page 36 Press the icon again to stop your clip. You can start and stop multiple times to create one continuous clip with multiple segments. Once you have captured your video, press the “Done” button in the top-right corner and allow a few seconds for your video to process.
  • Page 37 Once your video completely processes, you can click to preview. In the Preview menu you’ll have the ability to add music, color filters, or apply slow and fast motion to the video, to create an awesome, fully immersive 360° clip. See below for more details on adding music, filters, and playback speed adjustment.
  • Page 38 saved as a shareable 16:9 video clip; capturing your unique point of view, ready to share with the world. After launching the Watch Me tool, select the “Play” icon to start reviewing your video. At the icon to start capturing. You’ll location that you would like to begin your clip, press the notice a green status ring around the icon indicating the time you have left in your capture session.
  • Page 39 When complete, click on the “Done” button and allow a few seconds for your video to process. You can now add some special effects like music, slow/fast motion, or change the image filter to apply a unique color scheme to your clip. See below for more details on adding Music, Filters, and Playback speed adjustment.
  • Page 40 Your Watch Me videos are stored in your Android “Movie” folder and can be viewed on your phone and shared to social media sites in the same manner as any other movie file stored on your phone. Adding Filters: Tap the icon to select from an array of filters and color enhancements for your video clip.
  • Page 41 Note: Your device will need an internet connection to upload the video and post to your desired social networking sites. On some phones, if you are connected to the 360fly app, you’ll need to disconnect and re-establish your internet service prior to posting.
  • Page 42 .jpeg file format. Triggered Recording Modes The 360fly 4K camera features an array of automatic “triggered” recording options. Using this feature, your camera can be set to automatically record when it senses audio, video motion, or...
  • Page 43 To activate the triggered recording feature, tap the Settings icon located at the top-right of your display. Scroll down and locate the Triggered Recording Options within the list of menu items and select your desired triggered recording function by moving the slider to the right. Audio-Based Triggered Recording With this feature enabled, the camera will automatically launch a recording session when the camera senses an audible sound.
  • Page 44: Webcam Mode

    USB Connectivity Transferring Content to Your PC: Your 360fly 4K camera doubles as a USB mass storage device when connected to your PC or Mac. To access your camera’s stored content, simply connect your USB cable to your computer and place your camera onto its power cradle. Locate your 360fly camera within your computer’s folder browser to view and transfer your files to your desktop or the desired file folder.
  • Page 45 Note: Resetting will not wipe the videos stored within your camera’s memory. Tech Support and FAQs The 360fly team is always here to help. For all of your support needs, FAQ answers, or to report a bug, please visit us at www.360fly.com/support. Please be sure to check back regularly to learn...
