Congratulations on your
new 360fly 4K.
This powerful camera and its apps make you part
of an emerging community of visual storytellers
and explorers, one that is fundamentally changing
the way we experience and capture the world.
Join them and begin sharing and your best 360° 4K
videos, ideas and inspiration at 360fly.com.

Getting started.

Charging the battery:

To charge your camera, insert the USB cable into a USB
outlet adapter rated at 1.5A to 2.1A (most tablet charger
adapters) and plug it into the 360fly 4K Power Cradle.
Next, simply place the camera on the charger base. For
best results, charge your camera while it's powered off.
While your camera is charging, its LED indicator will
flash green. When your camera's fully charged, the LED
will remain solid green. It's recommended you charge
your camera for at least 30 minutes prior to its first use.
When your camera battery is low, the LED will display
a light purple color. Be sure to charge your camera
before using it when the LED is light purple.

Powering up:

Remove the camera from its Power Cradle and turn it
on by holding the OnePush button down for 4 seconds.
The triangular OnePush button is surrounded by the
LED indicator and located on the side of the camera.
When powering up, the camera will vibrate three
times and the LED will flash blue. After completing the
power-up sequence, the LED will display a solid blue
color, indicating that your camera is on and ready to fly.
You can also use the OnePush button to power down
your camera by holding the button down for 4 seconds.
The camera will vibrate four times to indicate that
it is powering down.

Camera care and storage:

A clean lens means cleaner footage. The 360fly 4K's
lens can be cleaned using a fine-thread, soft cloth.
Lens cleaning solution, water, or isopropyl alcohol
can be added for additional cleaning.
We highly recommend you store your 360fly 4K camera
in the provided neoprene pouch to help protect its
lens from scratching, chipping, or other damage.
Modified: June 13, 2016 3:23 PM
360fly 4K User's Guide
Miss Nothing.
The app powering it all.
Download the 360fly app:
The 360fly app is key to capturing your entire world
in 360° 4K video on your Android
search "360fly" in the Google Play
the free 360fly application to your mobile device.
Remember, the app allows your mobile device to serve
as your camera's remote control and viewfinder, giving
you the power to capture, edit, and share clips on the fly.
The first time launching the app, you'll see a brief
Shoot, Share, Swipe tutorial on recording, editing,
exploring and sharing full 360° video. Check it out.
It's well worth your time.
Create your 360fly account:
On the first app launch, you'll also be prompted to
build your 360fly.com profile. You can sign in using
your existing social media account, or you can sign
up with a unique 360fly.com account by entering
a new user name, email address, and setting a
password for your new profile. Signing in with your
social media accounts allows you to instantly
share and post videos with the click of a button.
You can also choose to skip the account creation
step by selecting "Skip" in the top-right corner.
Smartphone. Just
Store and download
Connecting to the 360fly 4K:
The application will lead you through a step-by-step
guide for establishing a Bluetooth LE and Wi-Fi
connection to your camera.
Note: A Wi-Fi connection is required to view your
camera's live feed and stored content. Check your
device settings to ensure that Wi-Fi is enabled prior
to connecting.
Once the power-up sequence is completed, your
360fly 4K will automatically enter pairing mode with
your mobile device. For best results, place your phone
www.360fly.com
facebook.com/360fly
twitter.com/360fly

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4K Miss Nothing and is the answer not in the manual?

Questions and answers

Summary of Contents for 360fly 4K Miss Nothing

  • Page 1 360fly 4K User’s Guide Miss Nothing. The app powering it all. Congratulations on your new 360fly 4K. Download the 360fly app: This powerful camera and its apps make you part of an emerging community of visual storytellers The 360fly app is key to capturing your entire world and explorers, one that is fundamentally changing in 360°...
  • Page 2 about 3–5” from your camera in order to get a good, Profile: Recording mode options: strong signal. Once the devices are paired, it’s time to give your camera a unique name and passcode. Your 360fly 4K camera offers five video recording Select the icon to view all of the video content Now your device will automatically connect to your...
  • Page 3 30 FPS mode: Accessing your camera’s screen. Use the slider located on the left of your display to adjust the sensitivity level of the panning feature. stored files: Get the highest resolution and frame rate combination available from your 360fly 4K by setting While connected to your camera’s home screen, Virtual reality headset playback: your device to record your videos as 2880x2880...
  • Page 4 and forth to select the section of your video that you Clip Capture: wish to adjust. Next, use the speed control bar to increase or decrease the playback speed faster or Edit and share your clips in their native 360° format. slower for that selection.
  • Page 5 Your camera’s reset button is located inside the mount screw housing. ©2016 360fly, Inc. All rights reserved. 360FLY, the 360FLY Logo, and the Fly Logo are trademarks of 360fly, Inc. For a complete list of patents, please visit www.360fly.com/patents. Modified: June 13, 2016 3:23 PM www.360fly.com...
