ROYAL ENTRANCE II (PG-2020-S-B)
Contents of Accessory box
x2 x2 x2 x2 x8 x8 x2
Do not jump nor dive from the step; you can be permanently injured.
To prevent electrocution use only BATTERY operated tools to
assemble the step.
To prevent drowning or injuries, do not use the step outside the pool
or to access a pool, and fasten the step firmly to the pool deck.
For 48,52,54''above-ground pool only.
The step must be installed per manufacturer's instructions.
Use of corrosive cleaning solutions can dammage the step components.
Remove the step from water when temperatures drop below freezing.
To prevent dammaging the step, never lift the step by its handrails.
The manufacturer is not responsible for damages or injuries caused by improper installation or use of the product.
Failing to install the Step Cup
To prevent pool liner puncture, install the Step Cup
A
x2
x2
x4
x2
x2
x1
x2 x16 x10

WARNING

Caution

will greatly reduce the steadiness of the step and will void the manufacturer warranty.
TM
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
Royal II Step Shell
x2
x1
x1
provided.
TM
Insertion of
2) With a flat screwdriver,
compress the Step
mushroom ring while pushing
it into the hole.
Light cap

Installation of the light cap.

1) Align the cap 2 guiding pins into the two top
holes in the step and snap in place.

Tools required (not included)

Use a 7/16'' wrench.
A philips socket screwdri-
ver bit is required.
Battery operated
cordless drill
Sand
(not included)
Step Cup in the step.
TM
1) Insert half of the step cup
mushroom in the hole, at
a 45 degree angle
Cup
TM
3) Twist the
Step Cup
ensure that its mushroom
has entirely cleared the wall
thickness. If it has, the
suction cup should rotate
freely.
MANUFACTURER WARRANTY
1 year on pool step.
1 year on hardware.
REV. 13/05/2018
