  • Page 1 The presentation of hot foods with intuitive touch control Operating Manual Installation & Technical Specifications...

  • Page 2: Table Of Contents

    Technical data ............................. 37 17.1 Dimensions ..........................37 Installation instructions ........................37 After sales service ..........................38 Appendix ............................. 39 Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com...
  • Page 3 Mutation 12.11.2018 textual adjustments, supplement safety instruction, new icon "hot surface" 22.05.2019 Supplement pt. no. 3 (warranty and liabilities) Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com...

  • Page 4: Introduction

    The manual must always be kept close to the unit and easily accessible. Important! Beer Grill AG cannot assume any responsibility or warranty obligations for any damage sustained due to non-adherence to the installation and operating instructions or due to improper use.

  • Page 5: Safety References

    It is absolutely prohibited to run the Culinario with empty water bins. Therefore the water level has to be checked continuously. Your Culinario is equipped with a warning for water level control. Beer Grill AG repudiates liability for consequential damage from running the Culinario with- out water! Heating dry (without water) Culinario must be equipped with universal frames.

  • Page 6: Cold Running

    – Replace broken items. – Refit shatter protection glass with bracket (see instruction 60-M-07-021-00). – Refill counter. – Counter is again ready for operation. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel.

  • Page 7: Glazing/Danger Of Accident

    Glazing/Danger of accident Beer counters are equipped with one sheet safety glass (ESG). Incorrect, badly mounted or damaged glass may fall out and cause serious injuries. Be sure to check before opening the self-service counter, but also after cleaning the glass (especially the front- glass) if: –...
  • Page 8 To refit the panels, simply proceed in the reverse order. Beer Grill take no responsibility for damage to glass panels due to improper handling during removal or replacement. Beer Grill AG...

  • Page 9: Warranty And Liabilities

    Warranty and liabilities Basically, the "General Terms and Conditions" of the Beer Grill AG company, Allmendstrasse 7, CH-5612 Villmergen, apply in which the details of the guarantee claims are regulated. Claims of warranty are excluded if they result from one or more of the following causes: –...

  • Page 10: Connecting Culinario

    2 L + N + PE c) 3 phases for GN 5/1 3 NAC 400 V, 50 Hz 3 L + N + PE Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel.

  • Page 11: Sanitary Connection

    1½". Dry Run Warning The Culinario Master Touch is equipped with a dry run warning. After 3 hours operation with water bowls, this emits an acoustic and visual signal and reduces the bottom burner to protect the materials.

  • Page 12: Operating Manual

    Setting key for light and heat Delete key Save key Save key NEW Time/Date key Language key Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com CH –...
  • Page 13 The control elements on the display are hidden after a certain amount of time without contact. To make them visible again, touch the touchscreen on any side. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...

  • Page 14: Turning On The Machine

    Ensure that the machine is plugged into the power supply in accordance with regulations. Now move the On/Off button (1) in position I. The Beer logo is shown during the start-up phase. The machine is ready to operate as soon as a product screen is displayed.

  • Page 15: Working With Default Settings

    (15) in the display. The bar disappears as soon as the required temperature has been reached. The heat-up time is reduced if the machine has already been warmed up. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 16: Working With A Water Bowl

    Working with a Water Bowl Example: Pastas, etc. 1. Browse with the scroll keys (3) and (7) to the desired product group and confirm your selection with the Confirmation key (6). Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...
  • Page 17 30 mm (indentation on the left and right wall of the water bowl). Now only use warm and demineralized water. Confirm with the Con- firmation key (6) when you have filled up the water. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.
  • Page 18 If your machine has the energy option (14) and it is active (gray symbol), the top burner and light remain off for energy saving purposes until this option is deactivated again. Here the bottom burner remains in operation. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 19: Working With Crushed Ice

    3. You have to pour ice into the dish after you select the dish. Confirm with Confirmation key (6) when you have filled with pan with ice. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...
  • Page 20 Here the bottom burner remains in operation. Attention: The values for the top burner and light are only shown when the energy option (14) is deactivated. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...

  • Page 21: Changing The Top/Bottom Burner And The Light 0 - 100

    For products with a drying tray, the bottom burner is limited to 40 %. For products with ice pans, the top burner and the bottom burner are switched off. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...

  • Page 22: Setting The Light Colour/Intensity 0 - 100

    3. Then log back out by first pressing the Login key (9) and then press the Confirmation key (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 23: Working With Programs

    10 Working with Programs Up to 999 freely definable programs can be saved in the Culinario Master Touch. 10.1 Loading Programs Press the program key (4) and select the desired program by pushing it between the red markers. Confirm your selection with the Confirmation key (6) and follow the additional steps on the displays.
  • Page 24 (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Attention: Programs can be overwritten! This can happen if the memory button (18) is pressed with changed settings and no other program name is entered. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...

  • Page 25: Deleting A Program

    Products which you do not use can be hidden. 11.1 Setting the Date and Time 1. Press the Login key (9) on the product level and log in with user level 2. Password Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...

  • Page 26: Changing The Language

    3. Then log back out by first pressing the Login key (9) and then press the Confirmation key (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 27: Hiding Products

    3. Then log back out by first pressing the Login key (9) and then press the Confirmation key (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 28: Showing All Products

    3. Then log back out by first pressing the Login key (9) and then press the Confirmation key (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 29: Changing A Default Tray/Dish

    3. Then log back out by first pressing the Login key (9) and then press the Confirmation key (6) without inputting a code. The login symbol (8) is hidden and you are logged out. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 30: Energy Option

    With a deactivated energy option (14) (symbol is black) the top burner and the LED light are active and the accompanying setting values can be changed. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel.

  • Page 31: Haccp Log

    13 HACCP Log The Culinario Master Touch saves all processes/steps including the setting values in a HACCP log as a SVG file to the integrated memory. This can then be transferred to a com- puter on a USB. In the following part of a HACCP Log you see the recorded data.

  • Page 32: Saving An Haccp Log Onto A Usb Stick

    Save HACCP 01.01.2009 – 15.10.2014 Delete save log to machine (Free log memory 96%) ? Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel.

  • Page 33: Reading Out A Happc Log On The Computer

    Connect the USB stick to your computer and open the CSV file with Excel. The file contains all of the saved information from your showcase. Beer Grill AG recommends that you output the HACCP log once a week. For information: A maximum of 2 blocks of 64 KB are saved in the internal memory.

  • Page 34: Cleaning

    Display The surface of the display is made of glass. Use a standard, non-abrasive, mild glass cleaner for cleaning. Do not spray the detergent directly on the display. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a...
  • Page 35 Important: When cleaning a 1E cabinet, additionally retain the glass panel on the front side with your other hand. Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com...

  • Page 36: Maintenance

    Correct insertion of the infrared heater Please insert the infrared heater exactly the way it is indicated on the drawings below. Attention danger of burning! Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel.

  • Page 37: Technical Data

    According to the drawing No.17Tb154-00 which includes Technical data sheet Specification of installation Installation instructions Built-in in closed niche (The drawings are attached) Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com...

  • Page 38: After Sales Service

    Dublin 22, D22FE04 Dublin number: (+353) 01 429 1500 Cork number: (+353)214310366 Email: info@broderickbros.ie Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel. +49 (0)71 61 659 876 info@beergrill.com CH – 5612 Villmergen D –...

  • Page 39: Appendix

    GN 4/1, Double/Single LED white No. 17Eb268-50 wiring diagram GN 5/1, Double/Single 4 colored No. 17Eb268-52 wiring diagram GN 5/1, Double/Single LED white Beer Grill AG Beer Grill GmbH Allmendstrasse 7 Tel. +41 (0)56 618 7800 Körnerstrasse 14 a Tel.
  • Page 40 Ers. durch: Elektrische Daten angepasst Ers. f r: 08.06.2017 Ind. Datum Name Aenderung Ind. Datum Name Aenderung Komm. Culinario Master Touch Gezeich. 11.02.2014 G.Affolter Technisches Datenblatt Gepr ft Fiche technique Massstab Blatt Technical data sheet Beer Grill AG CH - 5612 Villmergen 17Tb154-00A Tel.: +41 / (0) 56 618 78 00...
  • Page 41 Ind. Datum Name Aenderung Ind. Datum Name Aenderung Komm. Accessories! Plate **** and tray sliding unit are accessories. Culinario Master Touch Gezeich. 11.02.2014 G.Affolter They have to be ordered separately. Aufstellvorschriften Gepr ft Sp cification d'installation Blatt Schnittbrettschale Standardtiefe 200mm...
  • Page 42 Ers. durch: Elektrische Daten angepasst Ers. f r: 08.06.2017 Ind. Datum Name Aenderung Ind. Datum Name Aenderung Komm. Culinario Master Touch Gezeich. 11.02.2014 G.Affolter Breite A 2 Einbauvorschriften Gepr ft Instructions d'installation Schnittbrettschale Standardtiefe 200mm Blatt Massstab Spezialtiefe 300mm auf Bestellung...
  • Page 43 Name Aenderung Ind. Datum Name Aenderung Komm. Entr et sortie de l'air refroidissement sont toujour separer par des conduits air separ s Culinario Master Touch Gezeich. 11.02.2014 G.Affolter Einbau in geschlossene Nischen Gepr ft Important! Encastr dans niche ferm e Blatt...
