rotated carefully until the fleece can be reached from the other side.
Now, it is directed over the second directing roll and fixed on the accepting roll. This can be done
with tale as well. If the accepting roll is in place and the transformer is plugged in the mains, the level
switch can be lifted lightly by hand. The motor starts and the fleece is pulled taut.
garden ponds up to a volume of 5000 l

6. Technical data

Power supply motor
Transformer
Water inlet
Water outlet
overflow
Width opf the fleece roll
Maximum water level, if placed
in a filter sump
Dimensions (L x B x H

7. Accessories: Spare fleece rolls

Article number: 3051100191 spare roll Aquarium „Fine", 40g/m², 45m long
Article number: 3051100192 spare roll Pond „Standard", 20g/m², 90m long
Connections:
Water inlet
Water outlet
overflow

5. Set Up

Aquarium: The Rollermat can be placed into the filter sump below
the aquarium.
Alternatively, it can be placed above the water level, so that the
purified water can flow freely back into the aquarium.
placed inside of the filter sump, the water level in the sump is
always kept maximum 5 cm below the level of the water outlet.
The water flows freely through the filter.
Garden pond: The Rollermat is placed above the water level and is
supplied with water by a pump. The purified water flows freely back
into the pond.
The motor of the Rollermat has a power uptake of 4W and is
operated with 12V= safety voltage. A transformer is included.
For fresh and saltwater aquariums from 300 to 3000 l volume and
12V, 50/60Hz , 4 Watts
230V/50 Hz
D 63 glue connection, 1 ¾" thread
D 90 glue connection, 1 ¾" thread
D 40 glue connection, 1 " thread
42 cm
16 cm above the bottom oft he Rollermat
90 x 60 x 70 cm
ROLLERMAT:
63 mm tank union/glue fitting
90 mm tank union/glue fitting
40 mm tank union/glue fitting
Connections
If it is
