- Page 1 TruVision TVD-2101/4101 Dome Camera User Manual P/N 1072660A-EN • REV 1.0 • ISS 09OCT13...
- Page 2 Copyright © 2013 UTC Fire & Security. All rights reserved. Trademarks and The TruVision and Interlogix names and logo are trademarks of patents UTC Fire & Security. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
Day/Night mode 12 Image noise reduction 13 Defog 14 Function 15 Privacy mask area 17 Digital effect 17 Image adjustment 19 Protocol adjustment 21 Autofocus 23 OSD language 23 Exit 24 Specifications 24 Menu Tree 25 TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 4: Product Overview
Always use a 12 VDC or 24 VAC UL listed Class 2 power supply to power the camera. • Do not use the camera over the temperature range specifications: -30°C to +65°C (-22°F to 122°F) TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 5: Product Description
The onscreen display (OSD) control pad (Figure 3) is a five-direction pad that provides the ability to manually control the camera functions. Table 1 below lists the OSD control pad functions and describes their use. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 6 Press the center of the control pad to display the Main menu. If the selected item has its own menu, press the control pad to enter a Enter submenu. Press the control pad for 2 seconds to save all settings and exit the Main menu. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 7: Installation
Caution: Check for polarity when using a 12 VDC power supply. Adjust the lens The camera is mounted on a pan-tilt-twist (3-axis grimbal) rotating platform so that it is easy to adjust the camera orientation. See Figure 3 on page 6. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 8: Adjust The Focus And Zoom
1. Use the OSD control pad as shown in figure 2 or Coaxial Control as figure3 to adjust the camera zoom and focus. TELE (UP) – Zoom-in lens WIDE (DOWN) – Zoom-out lens FAR (RIGHT) - Adjust the lens focus NEAR (LEFT) - Adjust the lens focus TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 9: Programming
Defines the defog set up. Function Defines motion detection, privacy, digital effect, image adjustment, autofocus, language and OSD color set up. Exit Exits the menu and return to live mode. Changes made are saved. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 10: Exposure
Brightness: Select the Brightness level, value from 1 to 100. Iris Speed: Select the iris speed, value from 1 and 5. Exposure In the Main menu, go to Exposure and press Enter. The Exposure menu appears. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 11: Backlight
Digital wide dynamic range (DWDR) allows you to see details of objects in shadows or details of objects in bright areas that have high contrast between light and dark areas. An example is the headlights of a passing car. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 12 It is often used to help identify vehicle license plate numbers, for example. You can adjust and select the specific area to observe the target object located under strong spots of light. TruVision TVD-2101/4101 Dome Camera User Manual...
- Page 13 Manually adjust the white balance by blue gain only. The red gain is automatically adjusted when the blue gain is changed. Only use this function when there is steady light. Return Exit the menu and return to live mode. Changes made are saved. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 14: Day/Night Mode
Set the threshold level on how light it should be before switching from Night to Day mode. The values range from 0 to 160. Return Exit the menu and return to live mode. Changes made are saved. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 15: Image Noise Reduction
Image noise reduction Smart 3DNR noise reduction reduces the background noise in a low luminance environment with 2D + 3D filtering system. In the Main menu, select SMART 3DNR to set up noise reduction. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 16: Defog
In the main menu, select DE-FOG to enable the feature. There are three options: off, auto and manual. De-fog auto mode: Detect level: Set the detection level to enable. The values range from to 1 to 5. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 17: Function
Exit the menu and return to live mode. Changes made are saved. Function menus There are additional functions available under this menu. In the Main menu, select Function and press Enter. The Function menu appears, showing the options available. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 18 0 to 100. Motion view Choose whether to show motion blocks when the camera detects motion in the selected zone. Return Exit the menu and return to live mode. Changes made are saved. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 19: Privacy Mask Area
Return Exit the menu and return to live mode. Changes made are saved. Digital effect In the Function menu, go to D-effect and press Enter. The D-Effect menu appears, showing the options available. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 20 • Tilt: Set the tilt location when D-zoom is enabled. The values range from -100 to +100. Smart-zoom When a motion is detected in a pre-defined area, the camera picture will zoom in on the area and then zoom out. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 21: Image Adjustment
Neg. Image The NEG IMAGE Display the image in a negative exposed format. Image adjustment In the Function menu, go to Image Adj and press Enter. The Image Adjustment menu appears, showing the options available. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 22 Use the Defective Pixel Correction (DPC) function to enable the camera to digitally correct defective pixels using its image signal processor. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 23: Protocol Adjustment
Protocol adjustment In the Function menu, go to Comm ADJ and press Enter. The Comm ADJ menu appears, showing the options available. Camera title: The camera ID displayed on-screen can have up to 53 characters. TruVision TVD-2101/4101 Dome Camera User Manual... - Page 24 RS485: This function allows you to configure the camera’s RS485 protocol settings. • Camera ID: Set the camera ID. The values range from 1 to 255. • ID display: Enable or disable the ID display on screen. Press LEFT or RIGHT enable or disable. TruVision TVD-2101/4101 Dome Camera User Manual...
-
Page 25: Autofocus
16 languages are available. Press Right or Left to choose the language. The languages are: English, Korean, Japanese, Chinese Traditional, Chinese Simplified, Russian, French, Spanish, Italian, Portuguese, Dutch, German, Polish, Turkish, Hebrew, Arabic. TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 26: Exit
Max: 408 mA (Heater on) Power consumption 12 VDC / 2.4 W Max3.96 W（Heater on） 24 VAC / 2.2 W Max: 8.4 W (Heater on) Operating temperature -30 to 65°C (14 to 122°F) Weight 1130 g (2.49 lbs) TruVision TVD-2101/4101 Dome Camera User Manual... -
Page 27: Menu Tree
Menu Tree TruVision TVD-2101/4101 Dome Camera User Manual...
