Getting Started

Rear Connections

The connections panel can be found on the rear of the
subwoofer.
1. TV/DVD switch
Set to "TV" position to
listen to the TV input
source (2)
Set to "DVD" position to
listen to the DVD input
source (3, 4, 5, 6)
2. TV (L) and TV (R) input
3. Front Left (FL) and Front
Right (FR) input
Page 4
4. Surround Left (SL) and
Surround Right (SR) input
5. Center (CEN) input
6. Subwoofer (SW) input
7. Audio output (speakers)
8. AC power input
9. Power switch (on/off)
