Eaton RMQ-TITAN M22 Series Instruction Leaflet

RMQ-TITAN ®
M22-..., M22S-..., M22M-..., (M22...-...)
1 2
3
M22-MS
M = 1.2 - 2 Nm
(M = 10.6 - 17.7 lb-in)
M22-K... M22-CK10, 01
M22-LED..., f ∼ = 50 - 60 Hz M22-CLED..., f ∼ = 50 - 60 Hz
1
2
3
0.4 x 2 ... 0.8 x 5.5
M ≦ 0.8 Nm
(M ≦ 7.1 lb-in)
2
2 x 0.75 - 2.5 mm AWG18 -AWG14
– AWG18 -AWG14
2
2 x 0.75 - 1.5 mm AWG20 -AWG16
a
M22-(S)-...
(IEC/EN 60947)
M22...-D...+
M22-T-D
M22...-D(R)(P)...
M22...-DD...
M22...-DD...+
M22-T-D
M22-ST...
1 - 6 mm
(0.04" - 0.24")
M22-STDD...
3.2 mm
M22-CK...
(0.13")
M22-CLED...
M22-XAK...
M22-XZK...
M22-XBK...
+ 0.4 mm
22.3 mm
0
M22-XYK...
+0.015"
0.88" M22-CK11, 02, 20
0
M22-ST-...
START
M22...-D(R)(L)-...
M22-T-D
Instruction Leaflet
07/21 IL047018ZU
￫
IL04716002Z
IL
4
Z 2 0.4 x 2.5
0.6 x 3.5
0.8 x 5.5
≦ 2
0.6 x 3.5
2
3
1
8 mm (0.31")
￫
60/70 °C CU wire only
a ≧ b ≧ a ≧ b ≧
[mm] [in]
30 50 1.18 1.97
30 40 1.18 1.57
33 40 1.29 1.57
38 40 1.49 1.57
30 55 1.18 55
33 58 1.29 58
30 50 1.18 1.97
30 75 1.18 75
30 45 1.18 45
30 45 1.18 45
90 90 3.54 3.54
33 52 1.29 2.05
60 60 2.36 2.36
50 55 1.97 1.97
30 50 1.18 2.36
ST AR T
