- Page 1 SIGNAL TECHNOLOGIES SQ2-T ® USER’S MANUAL 2015...
- Page 2 Important Information This operating manual contains important safety information! Please read carefully and understand all of the in- formation before operating equipment. Save this manual for future use. The owner and/or user of this equipment must have an understanding of the manufacturer’s operating instructions and warnings before using the portable traffic signal system.
- Page 3 Introduction This manual will provide detailed information on programming, monitoring and maintenance, as well as setup and removal of the Horizon SQ2 Portable Traffic Signal System. Horizon Signal Technologies has a long history of providing ® high quality dependable portable traffic signal systems. Our signal systems are extremely versatile and are available with a wide variety of modular add-on options.
-
Page 4: Table Of Contents
Addressing Radios Basic Programming Special Programming Saving a Program in Memory System Clock System Mode System Options 3) FIGURES & DIAGRAMS SQ2-T Deployed Dimensions SQ2-T Stowed Dimensions SQ2-T Circuit Board Diagram Molded Trailer Plug 4) TROUBLESHOOTING Troubleshooting Guide Limited Warranty... - Page 5 SQ2-T DEPLOYMENT...
-
Page 6: Sq2-T Setup Procedures
1. Position the SQ2-T trailer for deployment. 2. Lower all stabilizer jacks and level the trailer. 3. Use hand crank to raise the signal to the deployed position. 4. Power the system on. 5. Repeat all steps for each SQ2-T trailer in the system. - Page 7 SQ2-T PROGRAMMING...
-
Page 8: The Controller
System Features ® The Horizon Signal system is capable of three modes of operation: • Radio - Wireless communication between all controllers in the system. • Cable - Wired communication between all controllers in the system. • Quartz - Synchronized timing of all controllers in the system via quartz clocks. Controllers do not communicate in this mode. -
Page 9: The Micro-Terminal
The Micro-Terminal The micro-terminal acts as a mechanism to enter programming data into the signal controllers. It also coordinates and synchronizes the signal controllers within a signal system. Any multi-phase micro-terminal can be used to program any multi-phase controller. The micro-terminal gets plugged into the face of the Controller via the Hirschmann plug located next to the Power toggle switch. -
Page 10: Assigning Controller Identities
Assigning Controller Identities Before a program can be entered, all of the controllers in the system must be communicating. To accomplish this, each controller is given an identity. Additionally, when using wireless communication, each radio must be assigned a “Master” or “Slave”... -
Page 11: Basic Programming
Basic Programming Programs can be edited or changed at any time while the Horizon Signal system is running. By plugging in the micro- terminal the user can create new programs without any effect on the current program. A new program that is created will be loaded during the next available Red Clearance time, and will be undetectable by motorists. -
Page 12: Special Programming
Special Programming Special Programs allow for more control than basic programs, allowing the user to adjust all settings and create custom signal groups for more advanced aplications. SYSTEM 1. From the Home Screen press “+” to access the System Menu. The first option is Sys- Programming tem Programming. - Page 13 15. If you would like this signal to remain Red until there is a vehicle detection, set Rest PROGRAM 1 in Red to “Yes.” Otherwise, set it to “No” to allow the signal to cycle normally. Rest in red No 16.
-
Page 14: Saving A Program In Memory
Saving a Program in Memory The memory storage function of the micro-terminal is accessible by pressing “+” from the home screen 2 times. Using the memory function allows the user to save up to 10 programs that can be loaded or edited for later use. Memory programs can be given unique names to identify them. -
Page 15: System Mode
System Mode The mode function of the micro-terminal is used to change between signal operation modes. This menu can also be accessed by simply pressing “E” from the home screen. Once inside this menu, the user can scroll through the various operational modes by using the “+”... -
Page 16: System Options
System Options When you are setting up a system for the first time, it is a good idea to check the controller’s settings. You can access these options by pressing “+” from the Home Screen and scanning through the SYSTEM menu until you see “System Options.” Press “E”... - Page 17 FIGURES AND DIAGRAMS...
-
Page 18: Sq2-T Deployed Dimensions
SQ2 Deployed Dimensions... -
Page 19: Sq2-T Stowed Dimensions
SQ2 Stowed Dimensions... -
Page 20: Sq2-T Circuit Board Diagram
Molded Trailer Plug Below is the Wiring Diagram for the 7-Pole Molded Standard Trailer RV Cord used on the SQ2-T trailer. The cords have encapsulated terminals and wires to form a single weather-tight, noncorrosive assembly. This feature keeps the moisture out and allows for a more secure connection. - Page 21 TROUBLESHOOTING...
-
Page 22: Troubleshooting Guide
Troubleshooting Guide In the event of a system error, the Micro-Terminal will display an error message which can be useful for diagnosing problems. Below is a short description of each of these messages. Error Message Description Reccommendation Line Error A break in communication Check radios to make sure they are powered. -
Page 23: Limited Warranty
HORIZON SIGNAL TECHNOLOGIES LIMITED WARRANTY Horizon Signal Technologies, hereinafter referred to as HST, warrants New or Used HST Equipment and accessories to be free from defects in material and workmanship for a period of two years from the date of receipt of goods, subject to the conditions and restrictions contained herein. - Page 24 horizon SIGNAL TECHNOLOGIES 5 CORPORATE BLVD READING, PA 19608 (800) 852-8796 www.horizonsignal.com...
