SPARKLE 417/8385 Assembly Instructions Manual

2 door robe
Hide thumbs

Advertisement

Quick Links

Download this manual
Sparkle - 2 Door Robe
Assembly Instructions -
Dimensions
Width - 70.3cm
Depth - 51.6cm
Height - 182.3cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please keep for future reference
417/8385
413/3052
414/1343
MADE IN
BRITAIN
Issue 3 - 02/10/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the 417/8385 and is the answer not in the manual?

Questions and answers

Related Manuals for SPARKLE 417/8385

Summary of Contents for SPARKLE 417/8385

  • Page 1 Sparkle - 2 Door Robe Assembly Instructions - 417/8385 Please keep for future reference 413/3052 414/1343 Dimensions Width - 70.3cm Depth - 51.6cm MADE IN Height - 182.3cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number)

  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 46kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 When applicable, remove any Please check you have all the panels listed below protective film before use...
  • Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
  • Page 5 Assembly Instructions Step 1 10mm Prepare the left side Screw 6 metal dowels into the left side Note: Tighten the metal dowels up fully against the panels. Finished Insert 2 large locking front edge nuts into the left side Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
  • Page 6 Assembly Instructions Step 2 Prepare the right side Screw 6 metal dowels into the right side Insert 2 large locking nuts into the right side Finished Tap 2 wooden dowels front edge into the right side To fit the rail holder screw through the top hole with screw into the mark hole drilled...
  • Page 7 Assembly Instructions Step 4 Fit the 2 horizontals to the right side Push the 2 horizontals onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to each horizontal Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
  • Page 8 Assembly Instructions Step 6 Fit the 2 rails Push the 2 rails onto the right side Use a screwdriver to tighten the large locking fitted to each rail Note: Support this rail until the left side has been fitted in the next step. Step 7 Fit the left side Push the left side...
  • Page 9 Assembly Instructions Step 8 Prepare the top Screw 6 metal dowels into the top Finished front edge Step 9 Polystyrene block Fit the top Note: To make it easier to fit the top and base panels, place polystyrene blocks from the packaging underneath the side panels to raise the...
  • Page 10 Assembly Instructions Step 10 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 11 Assembly Instructions Step 12 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 13 Prepare the 2 doors Push fit 4 hinges into each of the 2 doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
  • Page 12 Assembly Instructions Step 14 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
  • Page 13 Assembly Instructions Step 15 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
  • Page 14 Assembly Instructions Step 16 Screw Fit the overbalance Washer protector Wall fixing Strap (not supplied) Strap To prevent possible Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by fitting of the overbalance protector kit to the unit, or an alternative fixing method of your choice.
  • Page 16 ALR3194...
  • Page 17 Sparkle - 3 Drawer Bedside Assembly Instructions - 411/3436 Please keep for future reference 428/7094 418/1035 Dimensions Width - 38.1cm Depth - 39.6cm MADE IN Height - 57.1cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number)

  • Page 18: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 14kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 19 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 When applicable, remove any Please check you have all the panels listed below protective film before use...
  • Page 20 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
  • Page 21 Assembly Instructions Step 1 Prepare the 3 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels. Step 2 Prepare the drawer sides Insert a small locking into the hole shown on the left drawer side and the right...
  • Page 22 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
  • Page 23 Assembly Instructions Step 8 Prepare the left side Place 3 runners the left side shown. Slide back the top of runner and use the 2nd hole from the front Finished to fit the 1st screw front edge Slide the runner back the other way and fit the 2nd screw into...
  • Page 24 Assembly Instructions Step 9 Prepare the right side Place 3 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into Finished...
  • Page 25 Assembly Instructions Step 10 Prepare the 2 rails Insert 2 large locking nuts into each of 2 the rails Tap 2 wooden dowels into each of 2 the rails Step 11 Fit the the 2 rails to the right side Push the 2 rails onto the right side...
  • Page 26 Assembly Instructions Step 13 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 14 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to each of the sides Finished front edge...
  • Page 27 Assembly Instructions Step 16 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 28 Assembly Instructions Step 17 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer 2nd threaded sides hole between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2...
  • Page 29 Sparkle - 5 Drawer Chest Assembly Instructions - 412/1961 Please keep for future reference 395/7655 402/3124 Dimensions Width - 75.1cm Depth - 39.6cm MADE IN Height - 90.1cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number)
  • Page 30 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 31kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 31 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 When applicable, remove any Please check you have all the panels listed below protective film before use...
  • Page 32 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
  • Page 33 Assembly Instructions Step 1 Prepare the 5 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels. Step 2 Prepare the drawer sides Insert a small locking into the hole shown on the left drawer side and the right...
  • Page 34 Assembly Instructions Step 3 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
  • Page 35 Assembly Instructions Step 8 Prepare the left side Place 5 runners the left side shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
  • Page 36 Assembly Instructions Step 9 Prepare the right side Place 5 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and Finished front edge fit the 2nd screw...
  • Page 37 Assembly Instructions Step 10 Prepare the 3 rails Insert 2 large locking nuts into each of 3 the rails Tap 2 wooden dowels into each of 3 the rails Step 11 Fit the the 3 rails to the right side Push the 3 rails onto the right side...
  • Page 38 Assembly Instructions Step 13 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 14 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to each of the sides Finished front edge...
  • Page 39 Assembly Instructions Step 16 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 40 Assembly Instructions Step 18 Example Attach the Attach the Fit the overbalance Screw strap to the wall strap to the unit protector kit Washer Wall fixing Strap To prevent possible Strap (not supplied) overbalancing we Washer recommend that this unit is secured to a suitable Screw wall by fitting of the...
