Risers

The 12mm wide risers, specially developed for the
ARCUS 2 RS with Kevlar reinforcement allow the
pilot to adjust the speed of the ARCUS 2 RS using a
pulley system to suit his/her individual preference.
There is more information on using the speed
system in the section "Flying the ARCUS 2 RS".
WARNING
The paraglider is delivered ex factory with the
Maillon quick links secured using a strong thread-
locking compound Loctite© to prevent
unintentional opening. After service work, quick
links which have been opened must be secured
again against unintentional opening.

Technical Data

ARCUS 2 RS
Class
Canopy weight [kg]
Recommended take off
weight
(min - max) [kg]
Certified take off weight
(min - max) [kg]
Wing area projected [m²]
Wing span [m]
Number of cells
Number of riser
Maximum symmetrical
control travel at maximum
take off weight [cm]
Maximum speed system
travel [mm]
The Service book has extensive technical information, (*) in progress
14 Section 03
XS
B
4,4
60-78
58-78
18,9
10,9
57
4
> 55
140
Technical Description
Fig. 3 ARCUS 2 RS riser
S M
B B
4,8 5,1
80-95 92-105
75-95 85-105
21,5 23,1
11,6 12,0
57
57
4 4
> 60 > 65
140 155
L XL
B B
5,8
5,4
102-115 115-135
95-115 110-135
25,0 28,4
12,5 13,3
57 57
4
4
> 65 > 65
155 155
