- Page 1 PROFESSIONAL MIXING CONSOLE PMF600 User s Manual...
-
Page 2: Before You Start
2. CONTROL ELEMENTS 2.1 Front panel Your PMF600 comes with ten input channels , which only differ in terms of pad switch , peak LED and interface panel . Since the EQ effect ,monitor and level controls are identical on all channels , they will be described only once on the enclosed sheet . - Page 3 17 17 29 29 16 16 30 30 31 31 32 32 15 15 20 20 18 18 19 19 15 15 24 24 23 23 25 25 26 26 21 21 27 27 22 22 28 28 The FX control determines the signal level that is routed from the respective channel to the built-in effects processor .
- Page 4 When the TAPE OUT signal is connected to a tape deck whose output signal is routed back to the TAPE IN on the PMF600 feedback can be produced as soon as you start recording . Be sure to interrupt the connection to the TAPE IN before...
-
Page 5: Rear Panel
These two 1/4 TS jacks allow you to route the output signal to an external amplifier This allows you to , say , use only the mixing and effect section of the PMF600 . The signal is taken pre-power amp . Of course , you can also use only the left jack as a mono output . -
Page 6: Effects Processor
When using the BRIDGE loudspeaker output , NEVER use any of the other two connectors ( RIGHT/MONO MAIN and LEFT/MONITOR ) at the same time ! This is the LEFT/MONITOR loudspeaker output of your PMF600 , to which you can connect the left loudspeaker of a stereo system ( switch set to its upper position). - Page 7 Plate : Simulates the sound of plate reverberators and hence is a classic for drums (snare) and vocals . In comparison with the first variation , the second one features more high-end sparkle . Concert : Here , you can select between a small theater and a large hall . Although this program is similar to studio ( see below ) it features more presence which adds to its lively character .
- Page 8 : With the phaser , a second , phase-shifted signal is added to the original audio signal .This effect is often used for guitar sounds and keyboards . In the 70s, it was also extensively used for other instruments like electric pianos . The PMF600 offers you four different phaser variations . Rotary Speaker : The simulation of a classic effect that is normally generated with a very heavy enclosure comprising ( slow or fast ) rotating speakers .
- Page 9 SPECIAL FX SPECIAL FX 3-Voice Pitch : The pitch effect can be used to produce a cartoon-character type voice effect . LFO Bandpass : Filters , in general , influence the frequency response of a signal . A low-pass filter allows low frequencies to pass and suppresses high frequencies , while a high pass filter allows high frequencies to pass and suppresses low frequencies .
-
Page 10: Specification
Specification Model JF666 JF844 JF842 Item Input Sensitivity Mic-60dBm Line-20dBm Stereo CH In-20dB Tape In-10dB Aux Send-20dB Output Voltage 8V Max 90dB Less than 0.01%(at 1kHZ) THD(1kHz Full Power) 20Hz-20kHz 2dB Frequency Response Headphone Power Consumption Parametric EQ Hi 15dB/12kHz Mid 15dB/2.5kHz Low 15dB/80Hz Power Supply AC 95-120V 60Hz / AC 220-240V / 50-60Hz 280 460 270...
