6.3USBstoragedevicerequirements
·elementMcanusedevicesthatcomplywith
theUSBmassstoragestandard,butcannot
guaranteecompatibilitywithallstorage
devicesormemorycards.
·USBstoragedevicessupportFAT32,exFAT,
NTFSformats.
·IftheUSBstoragedeviceispartitioned,each
partitionwillbetreatedasaseparateddevice.
·WhenusingextensioncabletoconnectaUSB
storagedevicemayresultinunstable
connection.
·WhenusingaUSBhubtoconnecttheUSB
storagedevicetoelementM,itmaynotwork
properly.
·TheUSBportofelementMcannotsupply
morethan500mAtotheperipherals.
·IfUSBstoragedevicecomeswithapower
adapter,pleaseconnectpoweradaptertothe
storagedevice.
CAUTION
Matrix Audio is not responsible for data
loss, modification, or failure to the USB
storage devices. We strongly recommend
you back up the data in the USB storage
devicebeforeusingitonelementM.
6.4IIS-LVDSPort
TheIISportofelementMisastandard19-pinHDMI
connector.ItusesfoursetsofLVDSdifferentialsignals
totransmitIISdata.Itsupportsupto32Bit/768kHz
PCMsignalinputand1Bit/45.1MHzDSDsignalinput.
ThePCMformatisthestandardIISformat,theDSD
formatsupportstheoriginalDSDformat(NativeDSD)
andtheDSDformatofDoPencoding.
TheIISportofelementMiscompatiblewithTYPEA,
B,CandD.Theseare4differentinterfacedefinitions,
whichcanbeconfiguredinthe8thsettingoption.
Theportdefinitionasshownbellow:
IICSCL/DSD/PCM
IISstandarddefinition
IICSCL/DSD/PCM
IISreversedefinition
16
6.5TechnicalSpecifications
_
TYPE
A:
DigitalInput
COAXIAL&OPTICAL:
PCM16-24Bit/44.1kHz,48kHz,88.2kHz,96kHz,
176.4kHz,192kHz
DSDDSD64(DoP)
IIS-LVDS:
PCM16-32Bit/44.1kHz,48kHz,88.2kHz,96kHz,
TYPE _ B:
176.4kHz,192kHz,352.8kHz,384kHz,705.6kHz,
768kHz
DSDDSD64/128/256/(DoP)
DSDDSD64/128/256/512(Native)
Appendix
IISreversedefinition
IISreversedefinition
