IMPORTANT PLEASE READ!
ISSUE #1 NO PICTURE
Make sure your TV is turned to the correct Video line (AV Input/Video Input 1,2,3.etc. Consult the TV
manufacture if you need help setting the TV to the correct Video line. If you are going through a cable box,
contact your cable provider or the cable manufacture. Once your TV is turned to the correct video line, you
should see the "COBY" logo.
ISSUE #2 ROLLING, COLORLESS SCREEN
Make sure the Yellow Video wire is connected into the Video connection on the DVD player and on the TV
ISSUE #3 HAD A COLOR PICTURE, NOW RECEIVING A BLACK AND WHITE OR A
ROLLING SCREEN
The DVD has been set to the incorrect broadcast system. Press the N/P button on the remote to select the
correct broadcast system (make sure you do not have a disk in the tray while pressing the N/P button).
NTSC is for the United States TV broadcast system
ISSUE #4 NO SOUND OR BACK GROUND SOUND WITH NO VOICES
Make sure the Red and White wire is connected into your TV "AUDIO IN".
Make sure the Red and White wire is connected into the Front-L & Front-R.
Make sure the DVD player Audio setting Analog Out AC3 is set to 2 Channel.
ISSUE #5 PICTURE FADES DARK TO LIGHT
You cannot connect the DVD through your VCR, TV/VCR combo, Cable or Satellite.
If you cannot connect directly to the TV via a Yellow Video input, then you will need to purchase an RF
Modulator and a four-foot Coaxial wire at your local electronics store.
ISSUE #6 HAD PICTURE, NOW RECEIVING A BLACK OR BLUE SCREEN
The DVD player may be set to Progressive Scan Mode. You will need to change the Video mode from
Progressive Scan to Composite. Make sure you DO NOT have a disk in the tray. Point the remote control
directly at the DVD player, and then press the MODE button 2-3 times.
ISSUE #7 WHY CANT I GET THE MICROPHONE TO WORK
1) Turn
your TV to the correct Video line. Once your TV is turned to the correct video line, you
should see the "COBY" logo.
2) Connect the Microphone into Mic1or MIC2
3) Turn the microphone switch to the "ON" position
4) In front of the DVD player, adjust the MIC and Volume knob to "MAX"
5) On the DVD remote control, press the "MIC" button until "ON" appears and then
press the "KARAOKE" button until "Stereo" appears.
If you are still having difficulty setting up your new DVD player, please contact Customer
Service or Technical Support, Monday-Friday 8:00 AM – 11:00 PM EST, Saturday and
Sunday 9:00 AM – 11:00 PM EST. You can also reach us online at
customerservice@cobyusa.com
1-800-681-2629 OR 718-416-3197
COBY DVD615
COMMON TROUBLESHOOTING ISSUES
