- Page 1 OWNER'S MANUAL 16" X 24" SIDE CABINET M1624SC www.montezumastorage.com...
- Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.
-
Page 3: Specifications
NET WEIGHT: 93 lb (42 kg) INSIDE DRAWER DIMENSIONS: REF DIMENSIONS 18-1/4" W x 11-3/4" D x 28-7/8" H (46.5 cm W x 29.8 cm D x 73.4 cm H) WE RECOMMEND USING THIS SIDE CABINET WITH ANY MONTEZUMA 24" DEEP TOOL CABINET... -
Page 4: Parts List
PARTS LIST The keys are taped to the inside of the drawer. REF DESCRIPTION PART NUMBER M6 x 12 Hex Bolt 321051 Connector 241999 M6 x 20 Counter Sink Screw 320049 End Cover 314047 EVA Liner 600100 Hanger 241998 Right Slide 300381 Shelf Support 203902... - Page 5 M6 x 12 mm Hex Bolt Connector M6 x 20 Counter Sink Screw For attaching For attaching the side the connector cabinet to a tool cabinet For installing the hanger End Cover EVA Liner Hanger Pre-installed on side panel – remove when hanging For attaching to the For hanging the side on a tool cabinet...
- Page 6 Lock and Key Grommet For securing your valuables For cord access...
-
Page 7: Hanger Installation
HANGER INSTALLATION The hanger can be mounted on either side of a tool cabinet. If necessary, remove the side handles from the tool cabinet. To install the hanger, position it over the holes in the tool cabinet and attach using four M6 x 20 counter sink screws. -
Page 8: Shelf Installation
SIDE CABINET- CABINET CONNECTION Remove the end covers from the side panel of the side cabinet. Hang the side cabinet on your tool cabinet. Position the connector on the back of the side cabinet and tool cabinet. Attach to the side cabinet using two M6 x 12 hex bolts and to the tool cabinet with two M6 x 12 hex bolts. -
Page 9: Drawer Removal
RAISE AND RELEASE DRAWER FRONTS These units are equipped with raise and release drawer fronts. To open, lift up on the drawer front while pulling towards you. To close, shut the drawer firmly until the latch engages. Lift If the drawer does not stay closed, the hook may be bent, or it may be rubbing against the drawer slides. -
Page 10: Maintenance
MAINTENANCE Periodically clean the drawer fronts, trim, and other surfaces with mild detergent and water. Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff. Grease and oil can be removed with most standard cleaning fluids. - Page 11 This product is warranted to be free from defects in materials and workmanship for a period of five (5) years from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
