LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.
SPECIFICATIONS 4-DRAWER BASE CABINET MG30244BC OVERALL DIMENSIONS: 30-1/2" W x 24-1/8" D x 34-3/4" H (77.6 cm W x 61.3 cm D x 88.1 cm H) NET WEIGHT: 125.66 lb (57 kg) MAXIMUM WEIGHT CAPACITY: 500 lb (227 kg) MAXIMUM DRAWER CAPACITY: 100 lb (45 kg)
Page 4
2-DOOR STACKING CABINET MG3024STBC OVERALL DIMENSIONS: 30-1/2" W x 24" D x 40" H (77.6 cm W x 61 cm D x 101.6 cm H) NET WEIGHT: 62.83 lb (28.5 kg) MAXIMUM SHELF WEIGHT CAPACITY: 100 lb (45 kg) * Dimensions do not include adjustable feet. 1-DOOR WALL CABINET MG30201WC OVERALL DIMENSIONS:...
Page 5
2-DOOR TALL CABINET MG3024TBC OVERALL DIMENSIONS: 30-1/2" W x 24" D x 80" H (77.6 cm W x 61 cm D x 203.1 cm H) NET WEIGHT: 119.05 lb (54 kg) MAXIMUM SHELF WEIGHT CAPACITY: 100 lb (45 kg) * Dimensions do not include adjustable feet. PEGBOARD BACK WALL MGPB01 OVERALL DIMENSIONS:...
Page 6
POSTS MGPST01 OVERALL DIMENSIONS: 2-1/8" W x 1-1/4" D x 65-3/8" H (5.5 cm W x 3.1 cm D x 166.1 cm H) NET WEIGHT: 5.73 lb (2.6 kg) WORKTOPS Galvanized Steel: GVTOP3024 Stainless Steel: SSTOP3024 OVERALL DIMENSIONS: 30-1/2" W x 24" D x 1" H (77.6 cm W x 61 cm D x 2.7 cm H) NET WEIGHT: 25.35 lb (11.5 kg)
Page 7
4-DRAWER BASE CABINET PARTS LIST Galvanized steel and stainless steel worktops available. See page 6. The keys are taped to the top drawer of the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 Washer 324050 M6 x 65 Hex Tapping Screw 320316 End Cover...
Page 8
2-DOOR BASE CABINET PARTS LIST Galvanized steel and stainless steel worktops available. See page 6. The keys are taped inside the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 Washer 324050 M6 x 65 Hex Tapping Screw 320316 End Cover 314195...
Page 9
2-DOOR STACKING CABINET PARTS LIST The keys are taped inside the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 M6 x 35 Hex Flange Bolt 321208 Washer 324050 M6 x 65 Hex Tapping Screw 320316 End Cover 314195 Lock and Key...
Page 10
1-DOOR WALL CABINET PARTS LIST The keys are taped inside the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 Gas Strut 303002 End Cover 314195 Shelf Support 226078 Shelf 233955 Lock and Key 304178 M6 Hex Flange Nut 323085 M6 x 65 Hex Tapping Screw 320316...
Page 11
2-DOOR WALL CABINET PARTS LIST The keys are taped inside the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 Washer 324050 M6 x 65 Hex Tapping Screw 320316 End Cover 314195 Lock and Key 304178 Magnet 312033 Shelf...
Page 12
2-DOOR TALL CABINET PARTS LIST The keys are taped inside the cabinet. REF DESCRIPTION PART NUMBER M6 x 16 Hex Socket Head Screw 320327 Washer 324050 M6 x 65 Hex Tapping Screw 320316 Shelf 118986 Shelf Support 226078 Adjustable Feet 110068 M4 x 12 Phillips Head Bolt 320202...
Page 13
PEGBOARD BACK WALL AND POSTS PARTS LIST These parts are sufficient to attach one base cabinet to one wall cabinet. Pegboards and posts are sold separately. REF DESCRIPTION PART NUMBER Pegboard 226913 Post A 226911 Post B 240368 M6 x 16 Hex Socket Head Screw 320327 To order replacement parts, email service@qualitycraft.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST).
Page 14
4-DRAWER BASE CABINET ASSEMBLY Carefully lay the cabinet on its back, with a soft mat underneath for protection. Screw the four adjustable feet into the cabinet bottom. Turn the cabinet upright. To add a worktop, remove the top drawer from the cabinet. Attach the worktop to the cabinet using four M6 x 16 hex socket head screws.
Page 15
4-DRAWER BASE CABINET OPERATION RAISE AND RELEASE DRAWER FRONTS These units are equipped with raise and release drawer fronts. To open, lift up on the drawer front while pulling towards you. To close, shut the drawer firmly until the latch engages.
Page 16
2-DOOR BASE CABINET ASSEMBLY Carefully separate the front and back panels, allowing the side panels to unfold completely. Carefully lay the cabinet on its back, with a soft mat underneath for protection. Insert the lip of the bottom panel into the slot in the back of the cabinet. Tilt the bottom panel onto the bottom of the cabinet.
Page 17
Attach the bottom panel using eleven M6 x 16 hex socket head screws. Screw the four adjustable feet into the cabinet bottom. Turn the cabinet upright. To add a worktop, attach a bracket on either side of the worktop using two M6 x 16 hex socket head screws per bracket.
Page 18
Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports. WARNING: DO NOT STACK A 2-DOOR BASE CABINET ON TOP OF ANOTHER CABINET. IF YOU HAVE PURCHASED A PEGBOARD BACK WALL AND POST COMBINATION, PLEASE SEE PEGBOARD BACK WALL AND POST ASSEMBLY ON PAGE 35 TO COMPLETE ASSEMBLY.
Page 19
2-DOOR STACKING CABINET ASSEMBLY BOTTOM CABINET ASSEMBLY Choose one cabinet to be the bottom cabinet in your stack. Carefully separate the front and back panels, allowing the side panels to unfold completely. Carefully lay the cabinet on its back, with a soft mat underneath for protection. Insert the lip of the bottom panel into the slot in the back of the cabinet.
Page 20
Attach the bottom panel using eleven M6 x 16 hex socket head screws. Screw the four adjustable feet into the cabinet bottom. Turn the cabinet upright. Place the top panel on the cabinet, but do not attach.
Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports. TOP CABINET ASSEMBLY Choose another cabinet to be the top cabinet in your stack. Carefully separate the front and back panels, allowing the side panels to unfold completely.
Page 22
Carefully lay the cabinet on its back, with a soft mat underneath for protection. Insert the lip of the bottom panel into the slot in the back of the cabinet. Tilt the bottom panel onto the bottom of the cabinet. Make sure the holes align. Down Attach the bottom panel using eleven M6 x 16 hex socket head screws.
Page 23
Attach the top panel to the cabinet using eight M6 x 16 hex socket head screws. Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports.
Page 24
STACKING CABINETS Stack your top cabinet on top of your bottom cabinet. Attach your top cabinet to your bottom cabinet using four M6 x 35 hex flange bolts. SEE FINISHING INSTALLATION ON PAGE 37 FOR HOW TO INSTALL YOUR ASSEMBLED UNIT IN YOUR GARAGE.
Page 25
1-DOOR WALL CABINET ASSEMBLY Carefully separate the front and back panels, allowing the side panels to unfold completely. Carefully lay the cabinet on its back, with a soft mat underneath for protection. Insert the lip of the bottom panel into the slot in the back of the cabinet. Tilt the bottom panel onto the bottom of the cabinet.
Page 26
Attach the bottom panel using eleven M6 x 16 hex socket head screws. Turn the cabinet upright. Attach the top panel using eight M6 x 16 hex socket head screws. Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports.
Page 27
2-DOOR WALL CABINET ASSEMBLY Carefully separate the front and back panels, allowing the side panels to unfold completely. Carefully lay the cabinet on its back, with a soft mat underneath for protection. Insert the lip of the bottom panel into the slot in the back of the cabinet. Tilt the bottom panel onto the bottom of the cabinet.
Page 28
Attach the bottom panel using eleven M6 x 16 hex socket head screws. Turn the cabinet upright. Attach the top panel using eight M6 x 16 hex socket head screws. Insert four shelf supports inside the cabinet at the desired height. Place the shelf on the shelf supports.
Page 29
2-DOOR TALL CABINET ASSEMBLY Assemble the side panels. 1. Insert a stiffener to connect two panels together on one side. 2. On the same side as the stiffener, attach the two panels together using six M6 x 16 hex socket head screws. 3.
Page 30
Attach the bottom panel to the side panel using four M6 x 16 hex socket head screws. Screw the four adjustable feet into the cabinet bottom.
Page 31
Attach the top panel using four M6 x 16 hex socket head screws. Place the four back panels on the back of the cabinet, starting at the top and working down. Attach using seventeen M6 x 16 hex socket head screws.
Page 32
Secure the front corners of the cabinet with eight M6 x 16 hex socket head screws Insert twelve shelf supports inside the cabinet at the desired heights. Place the three shelves on the shelf supports. NOTE: One shelf must be placed on the fourth set of holes, or the unit will not close properly.
Page 33
Assemble the doors. NOTE: Panel B connects to Panel D, which has a doorstop at the bottom. Panel A connects to panel C, which does not have a doorstop at the bottom. 1. Insert a middle door pull to connect two panels together on one side. 2.
Page 34
Install the door with the doorstop on the left hand side. Install the door with the lock on the right hand side, with the lock on the top. 1. Partially screw eight M4 x 12 Phillips head bolts into the cabinet. Hang the door on the screws.
Page 35
PEGBOARD BACK WALL AND POST ASSEMBLY You can use a pegboard back wall and post combination to attach one base cabinet and one wall cabinet. Attach two A posts to the back of the base cabinet using three M6 x 16 hex socket head screws per post.
Page 36
Slide two A posts onto the B posts. Make sure to leave enough room at the top for the wall cabinet. Place one pegboard on the front, making sure the grommet hole is on the top. Attach using two M6 x 16 hex socket head screws per post.
FINISHING INSTALLATION For a better appearance, attach units together using a M6 hex flange nut and washer. Holes are located at the top front side of each unit. Hide holes on the exterior ends of the units with the supplied end covers. For safety, secure the tops of the each unit to the wall using three M6 x 65 hex tapping screws and washers.
MAINTENANCE Periodically clean the door and drawer fronts, trim, and other surfaces with mild detergent and water. Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff. Grease and oil can be removed with most standard cleaning fluids.
