- Page 1 9292 Jeronimo Road Irvine, CA 92618-1905 EdgeReader & EdgePlus Quick Installation Guide © 2006 HID Global Corporation. All rights reserved. Document Version 1.4 April 27, 2007 Document Number 82000-901A.2...
-
Page 2: Table Of Contents
Step 3 Configure ...............................6 Edge Device Communications ....................6 Step 4 Communicate ............................8 Appendices ..............................9 Troubleshooting ............................9 Firewall ..............................11 Contact Information ............................11 Certifications ..............................12 Configuration Checklist ..........................14 April 2007 Page 2 of 14 © 2007 HID Global Corporation. All rights reserved. -
Page 3: Introduction
Today, as more IT departments become involved in the security system implementation decision- making process, they prefer that access control be managed over the network. The EdgeReader and EdgePlus address this by offering an IP-based solution incorporating PoE capability that takes advantage of existing LAN and CAT-5 cable infrastructure. -
Page 4: Overview
EdgeReader and EdgePlus Installation Part No. 82000-901 Overview The following outlines what is required to install the Edge device. April 2007 Page 4 of 14 © 2007 HID Global Corporation. All rights reserved. -
Page 5: Step 1 Connect
6. Select the Installation folder and who should have access to the Discovery Client, click Next 7. Confirm the installation location, click Next 8. Click Close April 2007 Page 5 of 14 © 2007 HID Global Corporation. All rights reserved. -
Page 6: Virtual Port
The Edge device communications configuration is provided through a browser-based application called the Configuration GUI (Graphic User Interface). Access a web browser and enter the Edge devices IP Address into the Address field. April 2007 Page 6 of 14 © 2007 HID Global Corporation. All rights reserved. - Page 7 Once configuration changes have been made, click Submit, and the Confirmation page (see 3.1.4 Confirmation, page 8) will display. April 2007 Page 7 of 14 © 2007 HID Global Corporation. All rights reserved.
-
Page 8: Step 4 Communicate
2. Contact the host to test communications. Basic setup is now complete! Additional trouble-shooting tools are available through the System Status Supplemental Configuration (page 9) screens. April 2007 Page 8 of 14 © 2007 HID Global Corporation. All rights reserved. -
Page 9: Appendices
Custom Time Zone. If Custom Time Zone is selected, the TZ text box will be enabled. Otherwise, the TZ is associated with the Time Zone field. April 2007 Page 9 of 14 © 2007 HID Global Corporation. All rights reserved. - Page 10 Upon removing the jumper it takes approximately 60 seconds for the Edge device to reset. Once the reset is complete, the LED will return to green. 5. Configure the Edge device for your installation parameters. April 2007 Page 10 of 14 © 2007 HID Global Corporation. All rights reserved.
-
Page 11: Firewall
+44 1440 714 840 Asia-Pacific HID Asia Pacific Ltd. (Hong Kong) support: support_APAC@hidvertx.com sales: salesapac@hidvertx.com telephone: (852) 3160 9802 fax number: (852) 3160 4809 April 2007 Page 11 of 14 © 2007 HID Global Corporation. All rights reserved. -
Page 12: Certifications
FCC Class B Canada Class A CE Mark – Europe (EU) C-Tick – Australia and New Zealand VCCI – Japan April 2007 Page 12 of 14 © 2007 HID Global Corporation. All rights reserved. - Page 13 EdgeReader and EdgePlus Installation Part No. 82000-901 Intentional Blank April 2007 Page 13 of 14 © 2007 HID Global Corporation. All rights reserved.
-
Page 14: Configuration Checklist
FTP Enabled Telnet Enabled Virtual Port Enabled Host Addressing (IP Address or Host Name) Here I Am Interval (sec) TCP/IP Connection Port TCP/IP Listen Port Login Password April 2007 Page 14 of 14 © 2007 HID Global Corporation. All rights reserved.
