1. RATIONALE

The JS3 rudder pedals are designed to accommodate the largest possible shoe. Therefor the pedals are angled to
move more parallel with the fuselage nose section near the pedals.
JS designed two differently shaped footplates to be attached to the rudder pedals:
Type 1:
•
Part Numbers:
o
Rudder Pedal Footplate Left:
o
Rudder Pedal Footplate Right: 231 17 105 20
Type 2:
•
Part Numbers:
o
Rudder Pedal Footplate Flat Left:
o
Rudder Pedal Footplate Flat Right: 231 17 006 20
