Page 1: Front View
Video output Ground Audio signal DC 13V – 14V Front view LOCK AC120V Rear view... - Page 2 1. Handset 6. Monitor Button Lift to communicate Press this button to view the picture from with your visitors. the camera 2. 4” flat CRT 7. Call Button (intercom function) Press this button to communicate with monitor 2 or monitor 3 Power Lamp 8.
- Page 3 Connector pin configuration Video output Ground Audio signal DC 13V – 14V 1. Super infrared LEDs Let you see clearly even at night 3. Speaker Broadcasts the voice from the monitor 5. Call button Chime “ding dong” sound can be heard from inter-phone when this button is pressed, and the camera start working simultaneously Rear view...
-
Page 4: How To Install
HOW TO INSTALL INSTALLATION OF MONITOR 1. Attach the bracket to the wall, wherever you want to install the monitor. Secure the bracket with the supplied screws. 2. Connect the cable connectors with 4 wires in polarity to the wafer on the rear of the monitor. 3. - Page 5 NO.1:ON WALL NO.2:IN WALL NO.3:ON DOOR 1. Attach the bracket to the wall, wherever you want to install the camera. Secure the bracket with the supplied screws (Refer to the above illustration). 2. Connect the cable connectors with 4 wires in polarity to the wafer on the rear of the camera. 3.
