Clover TFT1904DVR Specifications

19" TFT LCD Monitor Built-in 4Ch DVR
19"
Front
Cameras
Specifications
Monitor
Monitor type TFT LCD
Viewable screen size 19"
Resolution 1280x1024 at 60 to 75Hz
Pixel Format RGB vertical stripe
Pixel Pitch 0.294(H) x 0.294 (V) mm
Contrast Ratio 500:01
Brightness 400cd/m²
Video Input 1.0Vp-p composite video
4 Din jacks
Video Output 1.0Vp-p composite video
Input Impedance 75 ohms
Dwell Time Programmable 0 to 10 sec
AC Power Source AC 90V to 240V, 50/60Hz
Power Consumption 70W
Operation Temp 32ºF to 104ºF
Dimensions 20.6" (W) x 15.8" (H) x 2.9"(D)
Weight 20Lbs
ELECTRONICS USA
Quility Price Service Synergy
www cloverusa com
with 4 Color Cameras
CLOVER Proudly Presents 19" Color TFT LCD Monitor/DVR Combo
Side
Built-In DVR
13073 E. 166th St.
Cerritos, CA 90703
T: 562-282-5700
F: 562-282-5800
877-327-5000 (Toll Free)

MONITOR FEATURES:

WALL WALL
Mount Mount
• 19" TFT LCD Monitor
• High Resolution 1280x1024 @60 to 75 Hz
• Contrast Ratio 500:1
• Brightness 400cd/m²
• Real Time Display & Record 120IPS
• 4 Video Inputs
• Remote Controlling & Monitoring via
TCP/IP
• Event Recording by Alarm & Motion
Detect
• Programmable Recording Speed
• Jog/Shuttle Ring
• USB 2.0 port for Back up
Camera
Image sensor 1/3" Color CCD Sensor
Resolution 330 TV Lines
Current Consumption 120mA
Electronic Iris NTSC: 1/60 to 1/100,000 Sec
PAL: 1/50 to 1/100,000 Sec
Lens 4.0mm C-Mount Lens
Back Light Compensation, AWB & AGC
60' Cable & Mounting Bracket
DVR
Resolution NTSC 720x480 / 360x240
PAL 720x576 / 360x288
Real time display Real Time
Recording frame rate 120 IPS, Programmable 1 to 30 Frames/sec
Algorithm MJPEG
Recording Schedule, Continuous, Event recording(Motion detection,Alarm)
Hard Disk Drive 160GB Hard Drive
Replay Forward, Backward (Fast, Normal, Stop, Pause)
Jog/Shuttle ring Easy search
Back Up Ethernet, USB
Alarm Input 4 Inputs
Alarm Output 1 Relay Output
Network Ethernet 10/100M
PACKAGE INCLUDES :
MODEL# TFT1904DVR
1- 19" TFT LCD Monitor w/Built-in DVR
2- Indoor Cameras w/C-mount Lens
2- Outdoor Day/Night Cameras
1- Remote Controller
(GUI, Web Browser)
1- Remote Client Software
4- 60' 6 pin Din Cable
1- AC Power Cable
1- Instruction Manual
1- Warranty Registration Card
