- Page 1 Logika Technologies Inc. 1250B Reid Street, Unit 12, Richmond Hill, ON Canada L4B 1G3 HMD-FOC Hot Metal Detector Static Mode Fiber Optical Cable Operator’s Manual Revision 1.02...
-
Page 2: Table Of Contents
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 Contents 1. INTRODUCTION ..........................2 2. DESCRIPTION ............................. 2 Model Nomenclature ..........................2 Specifications .............................. 3 Operating Principle ............................. 3 Sensitivity Adjustment ..........................3 3. OPTICAL LENS AND CABLE ......................4 A1 Lens................................ -
Page 3: Introduction
July 2016 1. Introduction The Logika Technologies static mode hot metal detector, Model HMD-ST-FOC, is designed to detect hot metals (above 360°C) and aid in the automation of steel, aluminum and other industrial applications. It includes a rugged IP66 enclosure protecting state-of-the-art electronics and will withstand the harsh ambient conditions present in heavy industrial environments. -
Page 4: Specifications
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 2.2 Specifications Electronics part -25˚C to +70˚C (-13˚F to +158˚F). Operating temp Detect Range 0.2-8m Response time Relay < 20 ms, PNP/NPN < 2 ms LED Indicators Green = power on, Red = target detect... -
Page 5: Optical Lens And Cable
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 3. Optical Lens and cable 3.1 A1 Lens Lens housing Cylindrical, Stainless Steel, with air purge Ambient Temperature -25 °C ~ 300 °C (-13 °F ~ 572°F) Field of View No Ring: 1.8°... -
Page 6: B1 Lens
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 3.2 B1 Lens Fiber Optical Cable Purge Fitting Hole Lens housing Cylindrical, Stainless Steel, with air purge Ambient temperature -25 °C ~ 300 °C (-13 °F ~ 572°F) Field of View 4.5°... -
Page 7: Hmd Enclosure
2-meter cable with a quick-connect assembly. This cable is also wired with ferrule terminals for the junction box connections. Custom cable lengths are available from Logika Technologies upon request. Cable Specifications Multi-lead cables – 11 x 0.34 mm²... -
Page 8: Purge Air Connection
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 Number Color Pin No. Function Brown +24VDC /AC L 0V DC/AC N Orange +24VDC Out Yellow 0VDC Out Green Earth Blue PNP (S) Purple Self test Gray Relay NO. White Relay COM Pink Relay NC. -
Page 9: Operation
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 5. Operation 5.1 Controls The HMD-ST-FOC’s control panel is located on the top of the housing. The following functions are available on the control panel. LED1 = Green: Power is on. -
Page 10: Troubleshooting
Logika Technologies HMD-FOC Operation Manual Rev 1.02 July 2016 NC (Normally Closed) pin (Pink) – Common (White) connected Connect Self test Pin (Purple) to 0VDC Pin (Yellow), Red LED will be ON. Use multi-meter to measure the voltages on PNP output Pin (Blue) and NPN output pin (Black), referring to 0VDC pin (Yellow): 1. -
Page 11: Returns Of Hmd-St-Foc
July 2016 6.2 Returns of HMD-ST-FOC Contact Logika Technologies at (1-888-856-4452 (1-888-8LOGIKA) with the Serial Number of your HMD before you return our product. If we are unable to solve the problem by phone or email, Logika will provide you with a return authorization number.
