2. EXPLODED VIEWS AND PARTS LIST

NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)

2.1 EXTERIOR SECTION

7
x4
5
4
[ Back side]
2
EXTER parts List
Mark No. Description
1 Lens R5
2 Key Eject R5
3 Front Bezel
4 Cover
5 Panel Sheet R6
5
6
mark on product are used for disassembly.
6
3
1
Part No.
DAC2148
DAC2057
DAH2141
DAH2230
DEB1614
6
7
UP case R5
Screw Screw
Low case R5
Screw
x4
8
Mark No. Description
6 Tray R5
7 Nail R5
8 Belt R5
DVR-A06
7
8
A
B
C
D
E
Part No.
DNK4075
DNK4076
DEB1542
F
5
8
