Summary of Contents for Chiroform Kinetec Kinevia

  • Page 1 Kinetec Kinevia™ Kinetec Kinevia Duo™ Avant toute utilisation, lire ce document. Manuel d’utilisation Kinetec SAS se réserve le droit de toutes modifications techniques. Before use, please read this document. Kinetec SAS reserves the right to effect technical modifications. User manual The English version is a translation of the original in French.
  • Page 3: Table Of Contents

    INFORMATION ABOUT THIS USER MANUAL ............................. 3 ..................................3 ANGER AND WARNING INDICATIONS ..................................3 ANGER AND WARNING SYMBOLS ....................................... 3 SER MANUAL PHOTOS GENERAL INFORMATION ABOUT THE KINETEC KINEVIA™ DEVICE ......................3 ........................................3 IELD OF USE ........................................4 NDICATIONS ......................................4 ONTRAINDICATIONS ........................................
  • Page 4 ARRANTY TERMS AND CONDITIONS ........................................38 LEANING ................................38 AINTENANCE AND SAFETY INSPECTIONS ..................................... 39 LIMINATION AND RECYCLING ....................................39 ECHNICAL SPECIFICATIONS ........................................ 40 YMBOLS USED ....................................41 ROUBLESHOOTING GUIDE ............................42 NFORMATION ABOUT ELECTROMAGNETIC COMPATIBILITY Kinetec Kinevia™ / Kinetec Kinevia Duo™ 2/44...
  • Page 5: Information About This User Manual

    General information about the Kinetec Kinevia™ device Field of use The Kinetec Kinevia™ motorised therapy trainer is designed to exercise the lower or upper limbs of patients who have limited movement capacity caused by neurological or neuromuscular pathologies. Kinevia is to be used as a: ◦...
  • Page 6: Indications

    ◦ Have a visual acuity ≥ 8/10th, with or without correction. ◦ Have a tactile sensitivity in order to use the touch panel. ◦ Have sufficient grip capability to hold the arm trainer handles. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 4/44...
  • Page 7: Intended Use Environment

    ◦ The use of accessories, spare parts or supplies not authorised by Kinetec SAS. ◦ Incorrect use. ◦ Use without consulting the attending physician or therapist. ◦ Failure to comply with the user manual. ◦ Negligence. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 5/44...
  • Page 8: Therapy Using Kinevia

    By default, the Kinevia will reverse the direction of rotation when a spasm is identified. The relaxation program eliminates cramps and relaxes the muscles in the event of spasms. Depending on needs, the antispastic control sensitivity can be adjusted to six level settings. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 6/44...
  • Page 9: Warnings And Safety Instructions

    Keep children at a distance, risk of suffocation or asphyxia from the accidental inhaling or swallowing of small objects that can cause serious lesions or death. Keep children at a distance, risk of strangling leading to serious brain damage or death. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 7/44...
  • Page 10 ◦ Make sure there is a correct distance between your seated position and the device position. Avoid stretching your articulations too much (see section 7.1 on page 19) ◦ We recommend starting training slowly and avoiding overloads. ◦ Not smoking is recommended during training. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 8/44...
  • Page 11 30 cm (12 inches) from any part of the Kinevia, including the cables specified by Kinetec. If this is not the case, the performances of those devices could be altered. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 9/44...
  • Page 12 (6), power supply and cables. The device must be disinfected before training sessions. Make sure that the foot pedals (5) and the arm trainer grips (9) rotate freely during training. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 10/44...
  • Page 13: Device Description

    ⑦ Support stands ⑧ ⑧ Transport castors ⑦ General view of the Kinetec Kinevia Duo™ upper and lower limb trainer The following additional control elements are an integral part of the arm trainer system: ⑨ ⑩ ⑨ Arm trainer grip ⑩...
  • Page 14: Detail View Of The Touch Screen

    Order reference: 4665010870 Tilt protection hooks The tilt protection hooks are fixed to the Kinevia front support stand and are attached to the wheelchair to prevent tipping over during training. Order reference: 4665009500 Kinetec Kinevia™ / Kinetec Kinevia Duo™ 12/44...
  • Page 15: Heart Rate Kit

    The arms are fixed using hook and loop bands. The hand support with forearm guide should only be used when auxiliary staff is present. Order reference: 4665010119 Kinetec Kinevia™ / Kinetec Kinevia Duo™ 13/44...
  • Page 16: Paediatric Foot Support

    Order reference: 4665040001 Kinetec Kinevia Cockpit™ Kinetec Kinevia Cockpit™ software is for use by healthcare professionals. It can be used to: - analyse and archive the training sessions for up to 100 users, - print training data or export it to a PDF file.
  • Page 17: Transport

    When being transported on stairs or uneven surfaces, the device must be carried by at least two people. Only use the device transport castors on hard, flat flooring. The external power supply must be fully removed from the device for transport. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 15/44...
  • Page 18: Foot Support Spacing Setting

    When making the settings, make sure the pedal arm is properly fixed. Check that the wing nut is properly tightened before each training session. If you experience difficulty unscrewing the wing nuts, use the loosening tool supplied below.  Kinetec Kinevia™ / Kinetec Kinevia Duo™ 16/44...
  • Page 19: Grip Height Setting

    WARNING DANGER DUE TO A LACK OF AUTONOMY Patients who are unable to remove the calf fixing themselves must not train without supervision. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 17/44...
  • Page 20: Starting The Kinevia Duo Arm Trainer

    It is not possible to use the arm and leg trainer at the same time. WARNING RISK OF INJURY DUE TO LEG POSITION WHEN USING THE ARM TRAINER The user’s feet must not be placed in the foot pedals when using the device as an arm trainer. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 18/44...
  • Page 21: Cardio Kit Settings

    - The chair must not tip backwards. - Do not use chairs fitted with castors (office chairs, for example). ◦ Sit straight and in a centred position. The chair or wheelchair must be centred facing the device. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 19/44...
  • Page 22: Using The Leg Trainer

    ◦ When in doubt, start your training sessions using the “soft” option in the “Guided training” menu. Training should be pleasant in order to maintain your long term motivation. After 4 to 6 weeks of daily training, the first positive effects are usually visible. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 20/44...
  • Page 23: Using The Touch Screen

    The screen turns off as soon as standby mode is activated. To reactivate the device from standby mode, press anywhere on the screen for about 5 seconds (see section 6.10 on page 19). Kinetec Kinevia™ / Kinetec Kinevia Duo™ 21/44...
  • Page 24: Main Key Functions

    To carry on the training session, press the “start” button again. To display the training analysis, press the “back” button To exit the therapy programme, press the “home “button. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 22/44...
  • Page 25: Training Menu

    A few seconds before the change of direction, the rotation speed drops gradually until it comes to a complete stop. The direction changes. Then the rotation speed increases gradually until it reaches the preset value. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 23/44...
  • Page 26: Training Command Panel Displays And Keys

    This field indicates the distance covered during the training session in km. ⑪ Calories: This field indicates the energy burned by your muscular work displayed in kcal. ⑫ Active power: This field indicates your active pedalling power displayed in Watts. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 24/44...
  • Page 27 All fields marked by a blue arrow can be updated during training: Training session duration Rotation speed Resistance Spasm control level Symmetry display (in active mode, displayed in graphic form) Heart rate (in cardio training mode) Examples: Kinetec Kinevia™ / Kinetec Kinevia Duo™ 25/44...
  • Page 28: Patient Entry And Exit Aid

    Always place your feet in front of the device forward support when they are not fixed in the foot supports. Make sure your feet or legs will not be touched by the foot supports during rotation. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 26/44...
  • Page 29: Asc - Antispastic Control

    Adapt the level of ASC sensitivity according to the physical capacities and state of health of the person who is training. The ASC function should only be disabled after having consulted your doctor or therapist. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 27/44...
  • Page 30: Other Settings During Training

    RISK OF INJURY THROUGH OVERLOADING It is preferable to start training sessions at low speed and then gradually increase depending on the physical capacities and state of health of the person who is training. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 28/44...
  • Page 31: Resistance

    TRAINING SETTINGS The preset values in guided training represent general training advice. It is essential that you define your training with your doctor or therapist and adapt these values to your personal needs. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 29/44...
  • Page 32  You can change the default values for each program using the “Settings” menu (see section 12.2 on page 35). Kinetec Kinevia™ / Kinetec Kinevia Duo™ 30/44...
  • Page 33: Training Phases

    EXCESSIVE TRAINING TIME Define training durations with your doctor or therapist and adapt the values if necessary. For the first training session, or after extended pauses in training, select an easy training level. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 31/44...
  • Page 34: Individual Training

    This field indicates the total training duration (in hours, minutes and seconds). ④ Duration active: This field indicates the proportion of training duration in active mode (in hours, minutes and seconds). ⑤ Kcal: This field indicates the expended energy (in kilocalories). Kinetec Kinevia™ / Kinetec Kinevia Duo™ 32/44...
  • Page 35 To view the saved training sessions, you can scroll forward and backwards through the displayed pages using the arrow keys. The respective training dates and times are displayed in the upper display bar.  All the training values are approximate values. Kinevia is not designed for diagnostic, monitoring or measurement purposes. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 33/44...
  • Page 36: Training Statistics

    Values displayed as maximum values for the analysis duration: ⑨⑫⑭⑯⑱  All the training values are approximate values. Kinevia is not designed for diagnostic, monitoring or measurement purposes. Settings This menu is used to configure different Kinevia and training settings. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 34/44...
  • Page 37: Training Duration

    ◦ Factory settings: is used to reset all the Kinevia settings to their default values, such as duration and training settings (see sections 0 and 12.2), statistics (see section 0), … Kinetec Kinevia™ / Kinetec Kinevia Duo™ 35/44...
  • Page 38: Automatic Spasm Detection (Asc)

    You can choose the screen display language settings using this menu. Scroll through the list of available languages using the arrows and press the required language. A beep indicates a successful language change. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 36/44...
  • Page 39: Product Information

    You therefore have a duty to keep the exchanged parts until the warranty application case is closed and Kinetec has provided a written validation. Exchanged parts become the property of Kinetec. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 37/44...
  • Page 40: Cleaning

    Kinetec recommends subjecting the device to annual maintenance in order to check the condition of the belt as well as ® different device elements. Please contact your Kinetec dealer to carry out this operation. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 38/44...
  • Page 41: Elimination And Recycling

    Storage / transport conditions ....: Ambient temperature ..: -25°C to +70°C Relative humidity ....: from 20% to 90% without condensation Atmospheric pressure ..: from 700 hPa to 1060 hPa Kinetec Kinevia™ / Kinetec Kinevia Duo™ 39/44...
  • Page 42: Symbols Used

    Do not stack Box storage direction Fragile Atmospheric pressure limits Humidity limits during storage Keep dry during storage and transport and transport Temperature limits during OFF (power off) ON (power on) storage and transport Kinetec Kinevia™ / Kinetec Kinevia Duo™ 40/44...
  • Page 43: Troubleshooting Guide

    Check and correct the thoracic belt position. If you need to return the device or its accessories, first discuss the return and packaging specifications with Kinetec. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 41/44...
  • Page 44: Information About Electromagnetic Compatibility

    30 cm (12 inches) from any part of the device, including the cables specified by Kinetec. If this is not the case, the performances of those devices could be altered. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 42/44...
  • Page 45 250 cycles at 50Hz for 250 cycles at 50Hz IEC 61000-4-11 for 300 cycles at 60Hz for 300 cycles at 60Hz REMARK: U corresponds to the alternating network voltage before application of the test level. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 43/44...
  • Page 46 If abnormal performances are found, additional measurements may be needed, such as reorienting or moving the product. Kinetec Kinevia™ / Kinetec Kinevia Duo™ 44/44...
