- Page 1 ZSI-330 User Manual Issue 01 Page 1 of 30 ZSI-330 USER MANUAL ZSI-330 CCTV ISDN Controller Issue 01 MEYERTECH LIMITED...
-
Page 2: Table Of Contents
ZSI-330 User Manual Issue 01 Page 2 of 30 Contents Contents.................................... 2 Introduction ..................................3 What is a ZSI-330? ............................... 3 Operation ..................................4 Features..................................... 6 Camera switching ................................. 6 Alarm handling ................................6 Auxiliary Outputs ................................. 6 EFD support.................................. 6 Security.................................. -
Page 3: Introduction
ZSI-330. What is a ZSI-330? Intersite communications A ZSI-330 is part of the ZoneVu Site Controller family. It allows the interconnection of remote sites via an ISDN line. Video transmission The unit operates as a transmitter. -
Page 4: Operation
ZSI-330 User Manual Issue 01 Page 4 of 30 Operation MONITOR 1. Local operator 2. Export only over ISDN 3. Shared monitor output RS422/485 PT heads ZoneVu ZSI-330 x 16 ISDN 3rd party domes ZVK-77 RS422 PROJECT: ISS. DRN. CHKD. - Page 5 ZSI-330 User Manual Issue 01 Page 5 of 30 Installation See ZSI-330 Installation Guide – available from Meyertech Technical Support MEYERTECH LIMITED...
-
Page 6: Features
Energising a local relay • Sending a local camera to a preset It can take as an alarm source either its own contact alarm inputs or alarm inputs via a ZoneVu receiver (or supported 3 party dome – see ZSI-EFD support document). -
Page 7: Osd
ZSI-330 User Manual Issue 01 Page 7 of 30 Static caption A static caption can be set up for each of the 16 video inputs. Alarm caption An alarm caption can be set up for each of the 16 alarm contacts. -
Page 8: Configuration
Configuration of the ZSI-330 is done through the RS232 port using Meyertech’s Windows based configuration tool Mpower. The ZSI-330 detects when a lead is attached to the RS232 port using the MODE pins, and enters configuration mode. In configuration mode, the CPU LED flashes at a faster rate and the ZoneVu port is disabled. -
Page 9: Zonevu Port
ZSI-330 User Manual Issue 01 Page 9 of 30 ZoneVu Port MAC address The address that this unit will respond to when polled by a site controller. Only used when polling mode is set to slave Default = 1 Terminate When enabled a 120Ohm termination resistor is used on the receive input. -
Page 10: Telemetry
Port Select the port used to transmit telemetry. ZVR port would normally be used unless the receivers are connected through a separate site controller. ZoneVu port is used to route telemetry through the site controller (not currently supported). Default = ZVR... - Page 11 Set the site number for this controller. This is used when controlling the ZSI-330 from a remote site. Default = 1 Site controller present Tick this box if a site controller is attached to the ZoneVu port. DO NOT USE - This function is not yet supported. Default = No Control timeout Enter a timeout, in seconds, after which camera control will automatically be removed from a keyboard.
-
Page 12: Basic Dialup
ZSI-330 User Manual Issue 01 Page 12 of 30 Basic Dialup ISDN Initialisation A configuration string used to initialise the ISDN link, up to 80 characters in length. Initialisation is done only at power up. Re-power the unit for this to take effect. -
Page 13: Advanced Dialup
ZSI-330 User Manual Issue 01 Page 13 of 30 Advanced Dialup Maximum redial delay To avoid contention of phone lines when an outgoing call cannot be connected, a short pause is left to allow other equipment to connect. The maximum time for this delay can be configured. Range 1 - 65535... -
Page 14: Telephone
The telephone numbers for up to 20 sites can be configured. For each entry, the following can be configured Site enabled Tick this box to enable this entry in the phone list Default = Disabled Site The ZoneVu site number of the remote equipment Default = [none] MEYERTECH LIMITED... -
Page 15: Display
ZSI-330 User Manual Issue 01 Page 15 of 30 Telephone number #1 Enter the ISDN phone number of the remote site. Numbers can be unto 20 digits. Default = [blank] Telephone number #2 Enter the ISDN phone number for the second channel. This is often the same as the first number, or leave blank to make a single (low bandwidth) call. -
Page 16: Camera Captions
ZSI-330 User Manual Issue 01 Page 16 of 30 Alignment Align text on the left or right of the screen Default = Left Rows are numbered from 1 at the top, to 11 at the bottom. Defaults: Camera captions = 1... -
Page 17: Sequences
ZSI-330 User Manual Issue 01 Page 17 of 30 Sequences For each of the 4 configurable sequences, the following can be setup: Sequence Position A sequence can have up to 16 positions, limited by the sequence length. For each position in the sequence:... -
Page 18: Alarms
General settings for handling the various alarm inputs, and alarm conditions. Connection indicator An auxiliary relay output can be used to indicate when the ZSI-330 is using the ISDN line Relay number The auxiliary relay output number. Range 1 – 4. -
Page 19: Alarm Contacts
ZSI-330 User Manual Issue 01 Page 19 of 30 Start timeout The time, from the last time the monitor was switched, before the video detection sequence is started. The timeout is overridden when a remote operator disconnects a call, in which case the sequence starts immediately. -
Page 20: Alarm Contact Events
ZSI-330 User Manual Issue 01 Page 20 of 30 Caption The text to be displayed whilst the alarm is active. Up to 28 characters long. See also Display section for related settings. Default = Alarm 1 – 16 Enabled = Yes Alarm Contact Events Configure the actions to be taken when each contact input is triggered. - Page 21 ZSI-330 User Manual Issue 01 Page 21 of 30 Switch If enabled, the monitor will be switched, to view the selected camera. If multiple active alarms have the switch enabled, the most recent alarm will be displayed. Default = No Record If enabled, the video will be recorded immediately the alarm is triggered.
-
Page 22: Receiver Alarm Events
ZSI-330 User Manual Issue 01 Page 22 of 30 Receiver Alarm Events Configure the actions to be taken when an alarm is reported from a receiver. To enable alarm gathering from a receiver see the polling option in the Telemetry section. -
Page 23: Video Loss Events
ZSI-330 User Manual Issue 01 Page 23 of 30 Video Loss Events Configure the actions to be taken when video loss is detected on video input. See also the Video Loss Setup section for related settings. For each Video input 1 to 16, actions can be configured as described in the Alarm Contact Events section. -
Page 24: Video Loss Setup
ZSI-330 User Manual Issue 01 Page 24 of 30 Video Loss Setup For each video input, configure the way video loss detection is handled For each video input, the following is configurable: Internal Sync If enabled, a blank screen is displayed, with the message ‘Video Loss Detected’ in the middle, when a camera is selected which does not have a stable video input signal. -
Page 25: Enables
ZSI-330 User Manual Issue 01 Page 25 of 30 Enables Reserved for future use. MEYERTECH LIMITED... -
Page 26: Leds
Diagnostics LEDs Each serial communications port on the ZSI-330 has LEDs to indicate any Transmit and Receive activity. The CPU LED maintaining a steady 1Hz flash indicates that the controller has successfully powered up. It also indicates when configuration mode is active with a faster flash rate. -
Page 27: Support
2. The GRN will be logged by our staff along with the reported problem. 3. Pack the ZSI-330 into the original packing it was delivered in. Failure to do so means the unit may incur further damage in transit, which Meyertech cannot be responsible for. -
Page 28: Disposal
Issue 01 Page 28 of 30 c. Repair the ZSI-330 at a quoted cost. An official purchase order to cover the cost and return of the product will be required prior to commencement of repair. d. Advise you that the ZSI-330 is not repairable. You can then decide to have the product returned to you at the standard delivery charge or we can dispose of the product free of charge. -
Page 29: Warranty
ZSI-330 User Manual Issue 01 Page 29 of 30 Warranty Please refer to Meyertech Limited ‘Terms & Conditions of Sale of Goods & Services’ for interpretation. 1. If the Buyer establishes to the Seller's reasonable satisfaction that there is a defect in the materials... - Page 30 ZSI-330 User Manual Issue 01 Page 30 of 30 9. In the event that the Buyer discovers a material error which results in the Programmed Products not performing substantially in accordance with the Functional Specification, or the Licensed Programs not performing substantially in accordance with the relevant Program Documentation and notifies the Seller of the error within 90 days from the date of the Seller making available the respective software to the Buyer (the `warranty period") the Seller shall at its sole option either refund the price which...
