3
4A
4B
4C
Before START:
1. Set resolution: 1024 x 768 @ 85 Hz (maximum)
(Start – Settings – Control Panel – Display – tab "Settings")
2. Check manual of Computer (VGA, sound), Monitor, TV or VCR or Video Projector
3. Shut down the computer.
PC
1
Disconnect Monitor cable
PC
2
3
1
TELEVIEWER V2 QUICK INSTALLATION GUIDE
OVERVIEW
Connect VGA cable
Use:
a. USB power cable or
b. PS/2 Keyboard Power Cable
2
1
VGA OUT
Connect Monitor cable
VGA IN
Connect to "VGA In"
Overview
Connect
VGA
Connect
VGA
power
14135-va-qm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trust TELEVIEWER V2
Summary of Contents for Trust TELEVIEWER V2
- Page 1 TELEVIEWER V2 QUICK INSTALLATION GUIDE OVERVIEW Overview Before START: 1. Set resolution: 1024 x 768 @ 85 Hz (maximum) (Start – Settings – Control Panel – Display – tab “Settings”) 2. Check manual of Computer (VGA, sound), Monitor, TV or VCR or Video Projector 3.
- Page 2 TELEVIEWER V2 QUICK INSTALLATION GUIDE To DC-IN, Televiewer V2 Use powered USB-port PS/2 Keyboard Power To keyboard Connect Televiewer V2 to TV/VCR/Projector Use S-Video, Video or SCART cable. Check manual TV/VCR/Projector S-Video -> 4A Video Out -> 4B SCART -> 4C...
- Page 3 Use S-Video for best image quality Do not connect both Video/Scart and S-Video cable !! Use the Televiewer V2 to show pictures/photos, DVD or presentation on TV, VCR or Projector Set TV/VCR/Projector on correct input channel. Refer manual. SUPPORTED RESOLUTIONS...
