1.4 Switching the device on and off

The Lactate Scout 4 has a configuration/
display mode and a measuring mode,
both of which can be switched on and off
independently.
The configuration and display mode can be
switched on or off by holding down the OK
button for two seconds.
The measuring mode is switched on or off
when the sensor is inserted into the measuring
device, even if the measuring device was
previously switched off or is in configuration
and display mode. Removing the sensor
from the device will switch the measuring
device off.
The measuring device can be switched off by
holding down the OK button for two seconds.
The device will switch itself off if it is not used
for two minutes in configuration and display
mode or if the device is not used for two
minutes while the sensor is inserted in the
measuring device.
8

1.5 Display

An information line will be displayed in both
modes at the top of the display when the device
is switched on. This line provides information
about the battery level, the current time and the
active functions of the measuring device (5A).
In configuration and display mode, a symbol line
will also be displayed beneath the info line (5B).
This line uses corresponding symbols to indicate
the configuration and display mode menu/sub-
menu that the measuring device is in.
5
If symbols or numbers have a black background,
this means they can be selected and confirmed.
If symbols or numbers have a grey background,
this means they cannot be selected and
confirmed. The associated function needs to be
activated in the main menu (Chap. 3).
5A
5B
