- Page 1 March Networks 9000 R Series IP Recorder with RAID Models 9116 R, 9124 R, 9132 R, 9248 R, and 9264 R Installation Guide...
- Page 2 Copyright © 2021. March Networks Corporation. All rights reserved. Information in this document is subject to change without notice. MARCH NETWORKS, March Networks Command, March Networks Searchlight, March Networks RideSafe, and the MARCH NETWORKS logo are trademarks of March Networks Corporation. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Weight ............................... 14 Operating and Storage Temperature ....................14 Heat Dissipation ..........................14 Power Ratings ........................... 14 Video Capture Rates ..........................14 Front Panel LEDs ..........................15 Hard Drive Caddy LEDs........................16 9000 R Series IP Recorder with RAID Installation Guide... - Page 4 Replacing a Redundant Power Supply Module...................29 Replacing a Redundant Power Supply Module in a 2U Recorder ...........29 Replacing a Redundant Power Supply Module in a 1U Recorder ...........30 Turning the Recorder On and Off ......................31 9000 R Series IP Recorder with RAID Installation Guide...
-
Page 5: Chapter 1: Mandatory Regulations
Europe This equipment complies with the following EU directives: 2014/30/EU, 2014/35/EU, and 2011/65/EU. A Declaration of Conformity is available upon request. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 6: Environmental Directive Compliance
Mandatory Regulations Environmental Directive Compliance March Networks is committed to doing our part to protect the environment. March Networks is compliant with current RoHS and WEEE directives: • RoHS 2 or RoHS recast (directive 2011/65/EU) and its amendments • WEEE recast (directive 2012/19/EU) and its amendments Further details on corporate environmental policies and on RoHS and WEEE compliance are available from March Networks customer support. -
Page 7: Avis Sur La Batterie Lithium
Mandatory Regulations • Remplacer seulement avec les blocs de batterie de marque March Networks. • Ne pas modifier le bloc de batterie NiCd. • Ne pas ouvrir ou tenter d’ouvrir la batterie individuelle NiCd • Ne pas jeter le bloc de batterie dans le feu. -
Page 8: Avis De Sécurité
Reliable earthing: You must maintain reliable earthing of any rack-mounted equipment. Pay particular attention to connections other than direct connections to the branch circuit (for example, the use of power bars). 9000 R Series IP Recorder with RAID Installation Guide... -
Page 9: Précautions De Sécurité Pour Une Installation Dans Un Rack
9000 HP • 9248 R IP recorder with RAID • 9132 R IP recorder with RAID 9000 MP • 9124 R IP recorder with RAID • 9116 R IP recorder with RAID 9000 R Series IP Recorder with RAID Installation Guide... -
Page 10: Chapter 2: Feature Overview
Chapter 2 Feature Overview The 16, 24, 32, 48, or 64 channel 9000 R Series IP Recorder with RAID (Redundant Array of Independent Disks) is a scalable recording platform that supports high-resolution IP cameras. The models included are the 9116 R, 9124 R, 9132 R, the 9248 R, and the 9264 R. -
Page 11: Key Features
Key Features The 9000 R Series IP Recorder with RAID is available in five different models, the 9116 R, 9124 R, 9132 R, 9248 R, and 9264 R. The two larger models are also available with a hot spare drive option. -
Page 12: Packaging/Shipment Contents
Hard drive caddy keys • 4-post rack rail kit • Software DVD — The software can also be downloaded from the March Networks Partner Portal website. • Technical publications — Included on the software DVD, or you can also download hardware and software technical publications from the March Networks Partner Portal website. -
Page 13: Specifications
19 inches/48 centimeters Dimensions of the 2U Model (9248 R and 9264 R) 21 inches/53.3 centimeters 17 inches/43.5 centimeters 22.2 inches/56.3 centimeters 0.9 inches/2.2 centimeters 1.2in/3cm 3.5 inches/8.9 centimeters 19 inches/48 centimeters 9000 R Series IP Recorder with RAID Installation Guide... -
Page 14: Weight
Video Capture Rates The IP camera input capture rate is dependent on the resolution and quality of the images captured.The 9000 R series recorders accommodate a total recording rate of up to: • 400 Mbps for the 9264 R model •... -
Page 15: Front Panel Leds
For more information, see the Administrator Console User Manual or Command Enterprise and Client User Guide, available from the March Networks Partner Portal website. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 16: Hard Drive Caddy Leds
Use the Administrator Console or Command Client software application to review the health alert and determine a possible resolution. For more information, see the Administrator Console User Manual or Command Enterprise User Guide, available from the March Networks Partner Portal website. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 17: Usb Ports
USB cable, and support USB version 2.0. Two USB 2.0 Ports on back of 2U model (USB 2 and USB 3) Two USB 2.0 Ports on back of 1U model (USB 2 and USB 3) 9000 R Series IP Recorder with RAID Installation Guide... -
Page 18: Ethernet Ports And Hd Video Monitor Output
You can change the display time, choose which cameras to display, show the cameras in various size grids, and change the order that the cameras display using the Administrator Console. For more information, see the Administrator Console User Manual or online Help. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 19: Power Connections For Redundant Power Supply
Important: Ensure that you only use the AC power cords supplied with your recorder unit. Failure to use the correct power cords can result in damage to the power supply or unexpected power loss. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 20: Power Supply Module Leds
The following table lists the details of the LEDs for the 1U power supply modules. 1U Recorder — Power Supply LED Status LED State Power Supply Condition No AC power available or module failure. Green AC power available, module is functioning correctly. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 21: Hard Drives
9116 R, 9124 R, and 9132 R 1U models. The units must conform to these drive options to support RAID. Hard drives in the 9000 R series are hot swappable: you can remove and replace a hard drive without powering off the recorder. -
Page 22: Hard Drive Error Led Status
You will lose all the data on the RAID hard drive. • The 9000 R Series IP recorder with RAID is available with various hard drive capacities, but each of the drives in one recorder must be the same capacity to support RAID. -
Page 23: Hot Spare Hard Drive
When the copy is complete and the system is back to normal, the RAID degraded alert changes state to a green check mark in Command Client and Resolved in the Administrator console. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 24: Nicd Battery Pack And Lithium Battery
ATTENTION : Avant de remplacer les piles, lisez les « Avis pour les batteries » à la page 6. Utilisez uniquement des piles approuvées dans l'appareil. Avant de remplacer les piles, éteignez l'unité. Assurez- vous que les voyants LED à l'avant de l'unité s'éteignent avant de retirer le couvercle. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 25: Chapter 3: Unit Setup
Then, specify basic device configurations using the March Networks Administrator Console. The Administrator Console application is included on the provided software DVD. For more information, see the Administrator Console User Manual, available for download from the March Networks Partner Portal website. -
Page 26: Mounting The Recorder
ATTENTION : N'essayez PAS de monter l'enregistreur dans un rack de serveur à 2 montants, sauf si vous utilisez l'étagère de serveur March Networks (numéro de pièce 34916). Si vous ne disposez pas de l'étagère du serveur, vous devez monter l'enregistreur dans un rack de serveur à 4 montants. -
Page 27: Replacing A Hard Drive
Do not insert a hard drive from a recorder other than a 9000 R series with RAID. The 9000 R series with RAID does not support hard drives from any other recorder series, even for investigation purposes. - Page 28 When tightening the screws, use 4.3 in-lbs (inch pounds) of torque. Slide the caddy back into the recorder unit, close the door, and turn the key to secure the hard drive. 9000 R Series IP Recorder with RAID Installation Guide...
-
Page 29: Replacing A Redundant Power Supply Module
On the module that you want to replace, move the lever at the right of the module to the left to unlock the module from the recorder unit. Move this lever to the left Handle of module 9000 R Series IP Recorder with RAID Installation Guide... -
Page 30: Replacing A Redundant Power Supply Module In A 1U Recorder
Insert the new power supply module into the recorder until it clicks into place. Plug the AC power cord into the new power supply module. The LED on the new module turns green to indicate that it is functioning correctly. 9000 R Series IP Recorder with RAID Installation Guide... -
Page 31: Turning The Recorder On And Off
You can also turn the unit on or off by plugging in or unplugging both AC power cords. The redundant power supply requires that both cords are connected. If only one is connected, an alarm is triggered. 9000 R Series IP Recorder with RAID Installation Guide... - Page 32 Serial ATA (Serial Advanced Technology Attachment). A standard for connecting hard drives to a motherboard. The SATA standard is based on serial signaling technology. Universal serial bus. An interface between the recorder and add-on devices. 9000 R Series IP Recorder with RAID Installation Guide...
- Page 33 Companies worldwide use our software solutions to improve efficiency and compliance, reduce losses and risk, enhance customer service and compete more successfully. With deep roots in video security and networking, March Networks is also recognized as the leader in scalable, enterprise-class video management and hosted services.
