- Page 1 March Networks 9000 Series IP Recorder Models 9132, 9248, and 9264 INSTALLATION GUIDE...
- Page 2 Information in this document is subject to change without notice. MARCH NETWORKS, March Networks Command, March Networks Searchlight, March Networks RideSafe, and the MARCH NETWORKS logo are trademarks of March Networks Corporation. Infinova is a trademark of Infinova Corporation. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Operating and Storage Temperature ....................13 Heat Dissipation ........................... 13 Power Ratings ............................13 Video Capture Rates......................... 13 Front Panel LEDs........................14 Hard Drive Caddy LEDs ........................15 USB Ports........................... 16 Front USB.............................. 16 Back USB ............................... 16 9000 Series IP Recorder Installation Guide... - Page 4 NiCd Battery Pack ..........................20 Lithium Battery ............................ 20 Chapter 3: Unit Setup ..............21 Mounting the Recorder ......................22 Removing or Replacing Hard Drives ..................22 Installation Requirements....................... 22 Turning the Recorder On and Off.....................24 9000 Series IP Recorder Installation Guide...
-
Page 5: Chapter 1: Mandatory Regulations
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Europe This equipment complies with the following EU directives: 2014/30/EU, 2014/35/EU, and 2011/65/EU. A Declaration of Conformity is available upon request. 9000 Series IP Recorder Installation Guide... -
Page 6: Environmental Directive Compliance
Battery Notices CAUTION: There is risk of explosion if any battery is replaced with another battery of the incorrect type. Ensure that you only use the NiCd battery pack and lithium battery provided by March Networks. NiCd Battery Pack Notice The unit contains an internal NiCd battery pack that is used during power shortages. -
Page 7: Rack Mounting Safety Precautions
The procedures contained in this publication outline how to install or service components located inside the unit, requiring the removal of the cover. Installation and maintenance procedures requiring internal unit access are to be performed by qualified service personnel only. 9000 Series IP Recorder Installation Guide... -
Page 8: Shipping Notice
Shipment of the unit and components may expose the unit to temperature extremes. We recommend you allow the unit to return to room temperature prior to operation. Regulatory Model Definition Information The certification regulatory model names for the 9000 Series IP recorder are defined in the following table. Recorder Certification Regulatory Model Name •... -
Page 9: Chapter 2: Feature Overview
Chapter 2 Feature Overview The 32, 48, or 64 channel 9000 Series IP Recorders are scalable recording platforms that support high- resolution IP cameras. The models included are the 9132, the 9248, and the 9264. The 9000 Series IP Recorder offers outstanding video compression and storage, and can be managed using either the March Networks Command or the Visual Intelligence video management platforms. -
Page 10: Key Features
Key Features The 9000 Series IP Recorder comes in three different models, the 9132, 9248, and 9264. Physically, the 9248 and 9264 are both bigger models with up to 8 hard drives and a 2U height, and the 9132 is a smaller model with up to 4 hard drives and a 1U height. -
Page 11: Packaging/Shipment Contents
Hard drive caddy keys • 4-post rack rail kit • Software DVD — The software can also be downloaded from the March Networks Partner Portal website. • Technical publications — Included on the software DVD, or you can also download hardware and software technical publications from the March Networks Partner Portal website. -
Page 12: Specifications
0.8in/2cm 1.75 inches/4.5 centimeters 19 inches/48 centimeters Dimensions of the 2U Model (9248 and 9264) 21 inches/53.3 centimeters 17 inches/43.5 centimeters 22.2 inches/56.3 centimeters 0.9 inches/2.2 centimeters 1.2in/3cm 3.5 inches/8.9 centimeters 19 inches/48 centimeters 9000 Series IP Recorder Installation Guide... -
Page 13: Weight
9248 and 9264 models — 85 W typical, 210 W maximum Video Capture Rates The IP camera input capture rate is dependent on the resolution and quality of the images captured. The 9000 series recorders accommodate a total recording rate of up to: • 400 Mbps for the 9264 model •... -
Page 14: Front Panel Leds
Use the Administrator Console or Command Client software application to review the health alert and determine a possible resolution. For more information, see the Administrator Console User Manual Command Enterprise User Guide , available from the March Networks Partner Portal website. 9000 Series IP Recorder Installation Guide... -
Page 15: Hard Drive Caddy Leds
Use the Administrator Console or Command Client software application to review the health alert and determine a possible resolution. For more information, see the Administrator Console User Manual or Command Enterprise User Guide, available from the March Networks Partner Portal website. 9000 Series IP Recorder Installation Guide... -
Page 16: Usb Ports
USB cable, and support USB version 2.0. Two USB 2.0 Ports on back of 2U model (USB 2 and USB 3) Two USB 2.0 Ports on back of 1U model (USB 2 and USB 3) 9000 Series IP Recorder Installation Guide... -
Page 17: Ethernet Ports And Hd Video Monitor Output
You can change the display time, choose which cameras to display, show the cameras in various size grids, and change the order that the cameras display using the Administrator Console. For more information, see the Administrator Console User Manual or online Help. 9000 Series IP Recorder Installation Guide... -
Page 18: Power Connector
Connects the unit to a power source via a connected AC power cord. For the unit’s power ratings, see “Specifications” on page 12. For information on powering the unit, see “Turning the Recorder On and Off” on page 24. 9000 Series IP Recorder Installation Guide... -
Page 19: Hard Drives
There is a power On/Off opening at the front of the recorder, with a pin accessible button. This power On/Off is only intended for use when you must shut down the recorder to replace a hard drive. For information about installing hard drives, see “Removing or Replacing Hard Drives” on page 22. 9000 Series IP Recorder Installation Guide... -
Page 20: Nicd Battery Pack And Lithium Battery
Used by the unit to allow graceful shut down during power outages. The unit will perform a graceful shut down if power is removed for more than 15 seconds. Custom NiCd battery pack supplied by March Networks. Lithium Battery Provides backup power for the unit’s RTC (Real Time Clock). -
Page 21: Chapter 3: Unit Setup
Then, specify basic device configurations using the March Networks Administrator Console. The Administrator Console application is included on the provided software DVD. For more information, see the Administrator Console User Manual, available for download from the March Networks Partner Portal website. -
Page 22: Mounting The Recorder
Note: Do not insert a hard drive from a recorder other than a 9000 series. The 9000 series does not support hard drives from an 8000 series recorder (or any other recorder series), even for investigation purposes. - Page 23 Use the power On/Off pinhole to restart the recorder. Insert a paper clip into the hole and press gently to power up the recorder safely. The front panel LEDs allow you to monitor the recorder as it starts up. 9000 Series IP Recorder Installation Guide...
-
Page 24: Turning The Recorder On And Off
• For the 2U model (9248 and 9264), turn the power switch to the on or off position. • For the 1U model (9132), unplug or plug in the AC power cord. 9000 Series IP Recorder Installation Guide... - Page 25 Devices at your site that capture, store, and stream audio, video, and text data from connected devices. SATA Serial ATA (Serial Advanced Technology Attachment). A standard for connecting hard drives to a motherboard. The SATA standard is based on serial signaling technology. 9000 Series IP Recorder Installation Guide...
- Page 26 Glossary SMART Self-Monitoring Analysis and Reporting Technology. An interface between the recorder and the hard drive. Universal serial bus. An interface between the recorder and add-on devices. 9000 Series IP Recorder Installation Guide...
- Page 27 The steps we have taken affect all aspects of our organization and involve our senior management team, employees, suppliers, partners and customers. Visit the March Networks website for more information about our company and our commitment to social responsibility and environmental sustainability.
