Summary of Contents for Mars Purifier GENERATION Z PRO
- Page 1 GENERATION Z PRO INSTALLATION...
-
Page 2: Table Of Contents
Table of Contents Equipment package contents Name of each part Specification CADR Performance to ISO14644 m3/hr Performance Parameter Filter setup before use Setup Function Modes Maintenance Filter cleaning Filter replacement Smart phone connection Safety precautions Warranty... -
Page 3: Equipment Package Contents
Equipment package contents • 1 air purifier • 1 adapter • 1 user manual • 1 remote control... -
Page 4: Name Of Each Part
Name of Each Part Display Panel Protective cover Air Outlet Panel Air Inlet Panel Door Latch Motor Wheel HEPA filter UVC Lamp Carbon filter... -
Page 5: Specification
Specification Model Generation Z PRO CADR 1280m3/hr Coverage 150m2 Noise (dB(A)) <65db Power (W) 260W Voltage 220V Rated Frequency 50Hz Product dimension 1335x570x335mm Package Dimension 1410x640x390mm Package with 1430mmx670mmx430mm (55kg) Carton Net/ Gross weight 39kg/41kg... -
Page 6: Cadr Performance To Iso14644 M3/Hr
CADR Performance to ISO14644 m3/hr Speed Setting Generation Z 1280 Noise – Decibel Volume Speed Setting Generation Z (dB[A]) -
Page 7: Performance Parameter
Performance Parameter Model Generation Z PRO Virus removal rate >99.9% Bacterial removal rate >99.9% Ultraviolet wavelength 254nm Ultraviolet illumination 95uw/CM Ultraviolet leakege <1uw/CM UVC lamp power 8-72W (optional) - 2 bulbs Extinction rate of air natural >90% bacteria Per Hour Ozone concentration <0.012mg/m3... -
Page 8: Filter Setup Before Use
Before Use - Filter removal 1. Open the Filter cover 2. Take out the filter and cut open the plastic bag. Pull down on the filter cover handle to open Ensure there is no plastic remains around the purifier Pull the upper cover... -
Page 9: Setup
Setup 120cm Settings - To ensure optimum performance Keep the product at least 120cm from the ceiling Keep the product at least 30 cm from the wall 30cm... -
Page 10: Function
Function Humidity and temperature display Filter replacement indicator Timer Display Panel (PM 2.5 Value Display Indicators – speed, sleep. Ato, anion, wifi Timer on Function button Switch operation mode Power Sleep mode Negative Ion On/Off Device button power On/Off Negative Ion On/Off... -
Page 11: Modes
Modes A. Manual mode: 3 Speeds adjust the air volume manually. B.Automatic mode automatically adjusts the wind speed according to the state of air quality. C.Timing mode: machine turn off time can be scheduled. the machine will automatically turn off after the scheduled 1-9 hours. D.sleep mode: operate with min wind speed and all the light will be turned off, Only sleep indicator light is on... -
Page 12: Maintenance
Maintenance External wiring - 3 months visually check for looseness Centrifugal fan and motor – 12 months the centrifugal fan must rotate smoothly without generating abnormal sound. If abnormal sound is heard, please confirm whether there is foreign matter in the blower and whether the noise of the motor bearing is abnormal. -
Page 13: Filter Cleaning
Filter Cleaning 1. When the machine works for about 2000 hours. please clean the air filter, use a brush to remove the dust on the filter and put it back, to ensure sufficient air volume. 2. Take out filter and Absorb the larger dust sticking around the filter Notice Be careful not to damage the surface of the filter Do not wash the filter... -
Page 14: Filter Replacement
Filter Replacement standard time for replacement is 1 year. About filter replacement time The replacement time will vary according to the method of use and the location where the product is set at. When used in places with heavy air pollution, the replacement time will be advanced Filter replacement warning light The ‘filter replacement’... -
Page 15: Smart Phone Connection
Smart phone connection - Tutorial Scan QR code to download app Touch the on/off button of the machine t start the machine. Then touch the WiFi button for 3-5 seconds. When you hear a buzzer sound, you can release your hand. At this time, the indicator light go the WiFi button flashes (a stable signal near the device shout router) Find the installed APP icon, click open, and register After complete ting the password setting, you will enter the following page, click “Add Device”, select small appliance, select air purifier, and enter the machine distribution network page. - Page 16 4. Follow the on screen instructions...
- Page 17 7. After successful network configuration, click “Finish” to enter the main page of device operation...
-
Page 18: Safety Precautions
Safety precautions Handling When moving, please make sure the purifier stops running and power plug is pulled out. Hold the firmly on the side of the machine to avoid excessive vibration or falling Installation Do not start the machine in case of danger The device air inlet should be at least 20cm from the wall or any other object. -
Page 19: Faq
SYMPTOM CONFIRM THE ITEMS HANDLING METHOD No exhaust air volume Check the filter is removed from the plastic bag Remove filter form packing bag No change air volume Check the filter is installed in correct way Double check that the filter is installed in the correct way The air volume is less than that when it was Check is there any dirt in the filter? It will effect the performance Clean the filter, if there is no improvement, it is necessary to replace with a... -
Page 20: Warranty
Warranty Name Address Post code Contact number Distributor Sale Date Product Name Manufacturer Serial Number This card should be filled clearly and sent back to our team for registration within one month after purchase.
