Summary of Contents for Mars Purifier GENERATION X
- Page 1 GENERATION X INSTALLATION...
-
Page 2: Table Of Contents
Table of Contents Equipment package contents Name of each part Specification CADR Performance to ISO14644 m3/hr Filter setup before use Install filter Setup Function Dust sensor Sensor Cleaning Filter cleaning Filter replacement Smart phone connection Safety precautions Warranty... -
Page 3: Equipment Package Contents
Equipment package contents • 1 air purifier • 1 adapter • 1 user manual... -
Page 4: Name Of Each Part
Name of Each Part Air Outlet Panel Display Panel Sensor Air Inlet Panel Air Inlet Panel On/Off Button Front Back... -
Page 5: Specification
Specification Model Generation X CADR 720m3/hr Coverage 70m2 Noise (dB(A)) <56db Power (W) 26W (or 46W ) Voltage 220V/50Hz Product dimension 276x276x570mm Package Dimension 310x310x610mm Net/ Gross weight 6.5kg/8kg... -
Page 6: Cadr Performance To Iso14644 M3/Hr
CADR Performance to ISO14644 m3/hr Speed Generation X Noise Decibel Volume Speed Generation X (dB) Power W Speed Generation X... -
Page 7: Filter Setup Before Use
Before Use - Filter removal 1. Open the Filter cover 3. Unlock the filter screen When changing the filter, place the purifier upside Take out the filter and cut open the plastic bag. down, use a stack of cloths to ensure it doesn’t get damaged Ensure there is no plastic remains around the purifier 2. Rotate counter clockwise to release the filter screen and unlock it (fig.2) -
Page 8: Install Filter
Install filter 4. Install the filter screen Take out the filter screen, gently put it into the purifier, adjust the position and lay it flat 5. Locking the filter Screen Rotate clockwise to lock the filter screen and finish the installation... -
Page 9: Setup
Setup 120cm Set up the machine, connect the adapter and then start Settings To ensure optimum performance Keep the product at least 120cm from the ceiling and 30 cm from the wall 30cm... -
Page 10: Function
Function Anion WiFi Sleep mode... -
Page 11: Dust Sensor
Dust Sensor This product is equipped with ‘Dust sensor’ which can detect pollution particles in the air At ‘Auto mode’ the sensory detects dust, can automatically control the air flow and start to work Substances easily detected – dust, mite corpses and excrements, pollen, fungus, mould spores, tobacco smoke and pet dander... -
Page 12: Sensor Cleaning
Cleaning method of sensor Clean once about every 3 months 1. open the cover plate of the dust sensor section 2. Use a blower to blow out the dust in the sensor... -
Page 13: Filter Cleaning
Filter Cleaning This filter is a combined HEPA with activated carbon, please reference the cleaning as follows 1. Absorb the larger dust sticking around the filter screen, etc. Notice Be careful not to damage the surface of the filter Do not wash the filter When removing the filter, if you touch the black surface (activated carbon) from the inside around the catalytic deodoriser device, your hands may get dirty... -
Page 14: Filter Replacement
Filter Replacement standard time for replacement is 1 year. In order to maintain the ultimate performance these units provide, it is important to replace the filter at the right time. The change indicator light is displayed on the air purifier when the filter needs to be replaced. Mars Purifier recommends that you replace your units filter approximately twice a year to maintain it's peak air cleaning efficiency. Recommended filter change: 6 months (4,380 hours) when used 24 hours a day The replacement time will vary according to the method of use and the location where the product is set at. When used in places with heavy air pollution, the replacement time will be advanced Mars Purifier indicator light is based on both the sensor and time. Filter replacement warning light The ‘filter reset’ lamp will flicker when the operating time reaches the filter’s lifetime according to the timer built in the machine. When the indicator lights up, it is recommended to replace the filter in order to maintain the performance of the machine Filter replacement warning light and reset way Press the ‘Filter’ button for 3 seconds to restore the reset function Notice In order to absorb and purify harmful gases, the formula activated carbon contained in the filter element may produce smell of slight acidity, which is a normal phenomenon. -
Page 15: Smart Phone Connection
Smart phone connection - Tutorial Touch the on/off button of the machine t start the machine. Then touch the WiFi button for 3-5 seconds. When you hear a buzzer sound, you can release your hand. At this time, the indicator light go the WiFi button flashes (a stable signal near the device shout router) Find the installed APP icon, click open, and register After complete ting the password setting, you will enter the following page, click “Add Device”, select small appliance, select air purifier, and enter the machine distribution network page. - Page 16 4. Follow the on screen instructions...
- Page 17 5. After successful network configuration, click “Finish” to enter the main page of device operation...
-
Page 18: Safety Precautions
Safety precautions Handling When moving, please make sure the purifier stops running and power plug is pulled out. Hold the firmly on the side of the machine to avoid excessive vibration or falling Installation Do not start the machine in case of danger The device air inlet should be at least 20cm from the wall or any other object. Power supply precautions Do not squeeze, bend or twist the power cord, as the inner cord may be exposed or broken Do not pull the power cord from the adapter when disconnecting the power cord. Do not use inappropriate AC outlet. Do not use the supplied power adapter on any other device AC power cord Use the power adapter and socket as indicated below to avoid fire, electric shock or damage. Please use only the supplied power adapter and do not use any other brand of power adapter Disconnect the adapters power cord from the AC socket before performing maintenance or moving the machine. In Use Stop using the product immediately if there is abnormal noise, peculiar smell, high temperature or the fan is rotating irregularly Do not put fingers or foreign objects into the protective gear, movable parts, air inlet and air outlet. Do not put hair, fabric, etc close to the main engine to avoid getting into or blocking the air inlet and outlet. Do not sit, lean on or tilt the machine. When used with the combustion unit, please ensure proper ventilation to avoid carbon monoxide positioning. Use limitation Do not use the machine in the following situations, otherwise electric shock, fire. And other damage may occur. Unstable places Bathroom, places with high temperature, high humidity and fire prone places. -
Page 19: Faq
SYMPTOM CONFIRM THE ITEMS HANDLING METHOD No exhaust air volume Check the filter is removed from the plastic bag Remove filter form packing bag No change air volume Check the filter is installed in correct way Double check that the filter is installed in the correct way The air volume is less than that when it was Check is there any dirt in the filter? It will effect the performance Clean the filter, if there is no improvement, it is necessary to replace with a purchased. Confirm if the current operation mode is auto mode? Or sleep mode? new filter. Please confirm if the operation mode can be changed through the mode switch button Although set to automatic mode, there is no Is the sensor blocked by walls or obstacles? If blocked remove the obstacles, if there is no obstacles clean the ‘sensor part’ response to dust and smell on the back of the machine. Smell Is the catalytic deodoriser of the filter new? Due to the use of high performance activated carbon as the raw material, the Is it used in the space where most people smoke or cook? smell will appear at the beginning of use, usually after a week or so, the initial “Catalyst deodorant device” contains activated carbon and so on, sometimes will give out a smell will weaken. weak odour. The filter has the property that can adsorb odour, so it can store odour Is it from another room? temporarily. After running for a short time, the odour will gradually weaken It can also be used after removing the “catalyst deodorant device”. There will be no deodorization effect at this time. Please put the catalytic deacrator device in plastic bags for storage. Sometimes it’s the smell of a previously used room. Over a short period of time, the odour will slowly diminish. Filter screen cleaning indicator light does not Whether the reset of filter screen replacement indicator is implemented Ease rest the filter screen replacement indicator. -
Page 20: Warranty
Warranty Name Address Post code Contact number Distributor Sale Date Product Name Manufacturer Serial Number This card should be filled clearly and sent back to our team for registration within one month after purchase.
