TASTIERA WIRELESS BIDIREZIONALE CON LETTORE NFC INTEGRAT0
BIDIRECTIONAL WIRELESS KEYPAD WITH NFC TAG READER
DESCRIZIONE / DESCRIPTION
ITALIANO
K-LCDW800 è una tastiera completamente wireless alimentata a batteria (2 batterie AAA - Alcalina 1.5V) con possibilità di alimen-
tazione esterna (4 - 18VDC).
E' dotata di un display LCD a 16 caratteri per 2 righe e di lettore tag NFC - RFID programmabile, con il quale è possibile armare e
disamare l'intero sistema e attivare uscite.
Essa emula in tutto una tastiera filare a livello di utenza finale, il sistema bidirezionale permette di avere un feedback reale dello
stato del sistema ogni volta che si agisce sulla tastiera.
Di seguito tutte le funzioni disponibili:
- ATTIVA E DISATTIVA IMPIANTO
- N0TIFICA ZONE NON PRONTE
- BYPASS ZONE
- CAMBIA CODICE PERSONALE
- CONSENTI ACCESSO INSTALLATORE
- MENU LETTURA EVENTI
- ATTIVA USCITE
- ABILITA TELEGESTIONE
- PROGRAMMA TAGS
- CANCELLA TAGS
ENGLISH
K-LCDW800 is a bidirectional wireless keypad powered by batteries (2 batteries AAA - Alkaline 1.5V)
IT can be powered with external power (4 - 18VDC)
It is equipped with a 16-character LCD display for 2 lines, and a programmable NFC-RFID tag reader, with which it is possible to
arm and disarm and enable/disable programmed outs.
K-LCDW800 is full bidirectional keypad and allows the user to have a real feedback of the state of the system (not ready zones,
troubles, etc.)
Below all the available functions:
- ARM AND DISARM PANEL (in all configurations)
- NOT READY ZONES ALERT
- BYPASS ZONES
- CHANGE/MODIFY PERSONAL USER CODE
- ALLOW TECHNICAL ACCESS
- LOG EVENT READING
- OUTPUTS TRIGGERING
- TAG READERS MANGEMENT
www.amcelettronica.com
K-LCDW800
1
MANUALE
INSTALLATORE
MANUAL
VER. 1.0
K-LCDW800 IT-EN v1.0
Advertisement
Table of Contents
Related Manuals for AMC K-LCDW800
Summary of Contents for AMC K-LCDW800
- Page 1 It is equipped with a 16-character LCD display for 2 lines, and a programmable NFC-RFID tag reader, with which it is possible to arm and disarm and enable/disable programmed outs. K-LCDW800 is full bidirectional keypad and allows the user to have a real feedback of the state of the system (not ready zones, troubles, etc.)
- Page 2 ENGLISH K-LCDW800, can work in 2 different ways, powered with batteries mode, or powered by external source. When it is powered with battery, the LCD display work only for the necessary time to do the actions, after it sleep. The NFC tag reader is in sleep mode, for wakeup press the down arrow and LCD disoplay will show the action of tag reder (see fig).
- Page 3 When is powered with batteries, the LCD dislay work only for the necessary time of operation, and after go in standby, the tag reader is in stanby, for wake up press down arrow. Note: with this keypad is not possible enter in technical menu www.amcelettronica.com K-LCDW800 IT-EN v1.0...
- Page 4 60mA - with external power 70mA ✔ Anti-opening ✔ Back tamper Alimetazione esterna / Ext. power 4 - 18Vdc Frequenza Trasmissione / Operating Frequency 868.3 MHz Condizioni Ambientali / Environmental Conditions da / from +5°C a / to +40°C www.amcelettronica.com K-LCDW800 IT-EN v1.0...
