Summary of Contents for AMC UNIKA
- Page 1 UNIKA TOUCH SCREEN KEYPAD MANUAL EN 50131-1 EN 50131-3 EN 50131-6 EN 50136-1 EN 50136-2 CLASS II www.amcelettronica.com UNIKA v.1.00...
-
Page 2: Important Notes
Fax +39031632781 Info@amcelettronica.com www.amcelettronica.com CONTENT OF THE PLASTIC & METAL BOX In the carton box there is: - UNIKA touch screen - user manual The packaging does not contain: -SD card - tag for use with internal tag reader - software for create the foto slide show for screen saver www.amcelettronica.com... -
Page 3: Introduction
INTRODUCTION Unika is a touch screen keypad for use with X and K panel from version 1.73 and 3.73 with certifification* EN 50131-1 + EN 50131-3 DEVICES FOR CONTROL OF THE SYSTEM There are 3 type of device for control of panel: Type A: Klcd and Klight (normal keypad) -
Page 4: Wall Mounting
WALL MOUNTING Unika is housed in BOX on Acrylonitrile-Butadiene-Styrene (ABS). UL94 V-0, with brominated flame retardant, without PBB / PBDE. For the drilling of the wall, use the figure that represents the measurements of the distances of the holes of plastic box. -
Page 5: Cabling
Connect the Unika to the bus of panel, without power supply, A & B and + & -. After connection power up the panel, if the the Unika is unique keypad connected, after few seconds will show the home screen. In case there is another different keypad (for ex. K blue) with address n°1 is necessary change the address on UNIKA. - Page 6 USER and the TAG profile following the panel manual. For delete tag, after code select, For use the tag on the keypad see figure below www.amcelettronica.com UNIKA v.1.00...
-
Page 7: Screen Saver
SCREENSAVER UNIKA has a screen saver system, that be configured with a photo slide show. For use the screen saver is necessary have a micro SD card and the software “slideshow”. For prepare the slide show file, open the soft and drag your photos inside, the soft will prepare 1 file that be copied in the SD card. -
Page 8: Installer Menu
For activate the panic press and hold the buttons for few seconds. TASK BAR In UNIKA home there is a info task bar on the top. In this bar it’s possible to see the info panel: - main power status...
