Start operation
- Protect the instrument from moisture and direct sunlight.
- Before switching the instrument on, make sure that sensor area is not wet.
If required, wipe the instrument by a dry clean cloth.
- If the instrument was subject to an extreme temperature change, allow it to adjust
to ambient temperature before switching on.
To switch on the instrument press and hold button
The instrument will automatically enter metal detection mode. In case the instrument
emits sound signal and red light indicator is blinking please carry out calibration:
place the instrument to an around no metal and strong magnetic field interference
environment (for example, hold the instrument up in the air), again press button
and hold it pressed until green light indicator is on and you hear beep sound.
Calibration is finished.
To switch off the instrument press and old button
In order to save battery power the product will switch off automatically within 5
minutes after the last operation.
Operating modes
The instrument detects objects by the sensor area.
Detection of metal objects
Press button to activate metal detection mode. Symbol
display, green light indicator will be on.
Put the instrument onto the surface to be scanned and move it sidewards. When the
instrument comes close to metal object, then detected object approximation degree
(0-100%) increases, light indicator becomes yellow, then red and sound
signal is emitted; when the instrument is moved away from the object, detected
8
CONDTROL SCAN
User Manual
for 2 seconds.
during 2 seconds.
will appear on the
ELECTRICAL WIRING AND
EN
HARDWARE SCANNER
object approximation degree
yellow, then green, no sound signal is emitted. If metal object is located right below
the centre of the sensor, symbol
metal detection depth value (in cm).
The accuracy of the depth value depends on shape of the objects to be measured and
its location. When the measured object is a normal rebar of 18mm diameter and it is
relatively parallel to the detector, the accuracy of the depth value is the best.
If detected metal object is ferrous (for example, steel) symbol
display.
If detected metal object is non-ferrous (for example, cooper) symbol
on the display. In order to distinguish between types of metal the instrument should
be located above detected metal object (red light indicator is on).
Detection of wooden objects
Press button to activate wood detection mode.
Place the instrument on even surface, press button
indicator becomes green. Calibration is finished, you can start operation.
Put the instrument onto the surface to be scanned and move it sidewards. When
the instrument comes close to wooden object, then detected object approximation
degree (0-100%) increases, light indicator becomes yellow, then red and
sound signal is emitted; when the instrument is moved away from the object,
detected object approximation degree
becomes yellow, then green, no sound signal is emitted. If wooden object is located
right below the centre of the sensor, symbol
CONDTROL SCAN
User Manual
(0-100%) decreases, light indicator becomes
appears on the display as well as
appears on the
and hold it until light
(0-100%) decreases, light indicator
appears on the display.
appears
