- Page 1 USER INSTRUCTION MANUAL BRUTE WINCH THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL: EN 80079-36:2016 EN 80079-37:2016 AFT730020 AND AFT730040...
-
Page 2: Performance And Limitations Of Use
Brute winche s are classed as rescue lifting devices by the European Machinery Directive 2006/42/EC and have been shown to comply with this Directive through the Harmonized European Standard EN1496 Class A [AFT730020 & AFT730040]. PERFORMANCE AND LIMITATIONS OF USE:... - Page 3 Must be used with a Retractable Fall Arrest Block when using as a Personal Winch raising or lowering. Ÿ Also available with the Stainless Steel Wire Rope instead of Galvanized wire rope. INSTRUCTIONS FOR INSTALLATION OF WINCH AFT730020 ON TRIPOD (AFT710007/AFT710010) Solid Pin Winch Pre-installed...
- Page 4 INSTRUCTIONS FOR INSTALLATION OF WINCH AFT730020 ON EXTREME STAINLESS DAVIT (AFT7500) Winch Cotter Canteliver Arm Step 01 Step 02 Step 03 Locate the Extreme Stainless Davit Use solid pin for locking the winch Lock the solid pin on mounting arm that has pre-installed mounting on pre-installed mounting bracket brackets using cotter pin.
- Page 5 INSPECTION: Visually inspect the system before each use to ensure that it is in a serviceable condition and is operating correctly. If during inspection, doubts are raised about the safety of the system or a component, these should be replaced either by the manufacturer or a competent person.
- Page 6 MARKING AFT730020 AFT730040 winch winch AFT730020 AFT730040 UID.: XXXXXXXXXXXX Max. Length: 40.0 mtrs Max. Length: 20.0 mtrs Norm: EN 1496:2017 Class A Norm: Mfg. Dt.: mm/yyy EN 1496:2017 Class A Rated Load: As per EN1496:2017: 135kgs Mfg. Dt.: mm/yyy As per Machine Directive...
- Page 7 LIFESPAN: The estimated product Lifespan is 10 years from the date of manufacture. The following factors can reduce the Lifespan of the product: intense use, contact with chemical substances, specially aggressive environments, extreme temperature exposure, UV exposure, abrasions, cuts, violent impacts, bad use or maintenance. DISCLAIMER: Prior to use, the end user must read and understand the manufacturer's instructions supplied with this product at the time of shipment and seek training from their employer's trained personnel on the proper usage of the product.
- Page 8 Certification Body : SATRA Technology Centre, Wyndham Way, Telford Way, Kettering, Northamptonshire, NN16 8SD, UK (Notified Body 0321) For EU Declaration, please visit https://kstrong.com/asia/eu-declaration-form/ KStrong Inc. 150 N. Radnor Chester Road Suite F200 Radnor, Pennsylvania 19087 United States Contact number : 1-833-KSTRONG www.kstrong.com...
