Review the user manual carefully prior to first use. To ensure proper product operation, pay special attention to the safety precautions. Retain this user manual for further reference. SAFETY PRECAUTIONS To avoid damage or injury to the user or third parties, read all instructions and safety recommendations prior to use of this product.
PARTS LIST: Reference Images Parts List Base and chair Back Support Rear Leg Connector Front Leg Neck support Backing Rollers Part # 1 Part # 2 Part # 3 Part # 4 Part # 5 Part # 6 Part # 7 Quantity 1 Quantity 1 Quantity 1...
ASSEMBLING INSTRUCTIONS Step 1 Attach the back support piece (# 2) to the base piece and seat (# 1) in the holes indicated with the dotted line of the drawing using the screw (# 22), washer (# 20) and nut (# 21) that are attached to the base piece and seat (# 1) using the 17mm (11/16”) wrench and the 5mm (13/64”) Allen key.
Page 6
Step 4 Place the front leg piece (# 5) in the connector piece (# 4) in the holes indicated with the dotted line. Using the screw (#14), washer (#21) and nut (#24) and place them in the base piece and seat (#1). Tighten the screw, washer and nut by using the 13mm (1/2”) wrench and a 5mm (13/64”) Allen key.
Page 7
Step 7 Insert the straight roller pieces (#9) into the horizontal tubes of the front leg (# 5) indicated with the dotted line. Next, place the grip pieces (#10) on the horizontal tubes of the front leg piece (#5) marked with the dotted line.
Page 8
Step 9 Insert the pedals (#31) into the threaded studs from where you previously removed the horizontal tubes attached to the middle of the front leg (# 5). Using the washers (#32) and nuts (#13) fix them by tightening them with the wrench. Finally, place the straight rollers (#8) in the horizontal tubes located on the upper part of the pedals (#31).
HOW TO USE Adjust the level of back support assistance. • To adjust the level of assistance it is necessary to place or remove the springs, only the upper part, identified by a hook that attaches to the bolts sides that are at the bottom of the back leg support (# 3) •...
Page 10
Resistance adjustment in cardio system • The Total Body Workout System has 3 levels of resistance in its cardio system to be used depending of the physical capabilities of the user. • To be able to modify the resistance level, loosen the PP nut, change the level and tighten again.
WARRANTY: Limited Lifetime Warranty Your Medic Therapeutics Total Body Workout System is backed by a limited lifetime manufacturer’s warranty. Medic Therapeutics will repair or replace your device at any time should it fail due to a defect in material or workmanship, subject to the certain limitations.
