- Page 1 1500W SDS DEMOLITION HAMMER MODEL NO: CON1500DD PART NO: 6479509 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1020 - ISS 1...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Demolition Hammer. The CON1500DD is designed for breaking breeze blocks, brick, hard earth and concrete etc. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR DEMOLITION HAMMER. WORK AREA 1. Keep work area clean and well lit. Cluttered and dark areas invite accidents. - Page 4 5. DO NOT overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. 6. Dress properly. DO NOT wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
-
Page 5: Specifications
SERVICE 1. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. SPECIFICATIONS Model No. CON1500DD Operating Voltage and Frequency 230V AC~ 50Hz -1phase Rated Input Power 1500W Chuck capacity/type... -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. Connecting it to any other power source may cause damage. - Page 7 OVERVIEW/CONTENTS NO DESCRIPTION NO DESCRIPTION SDS Hex Demolition hammer 34mm Flat Head Chisel Moulded Carrying Case Spanner Oil Bottle 5mm Hexagon Key Bull Point Chisel 6mm Hexagon Key Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 8: Before Use
BEFORE USE OIL GAUGE/OIL TOP UP This machine has an oil chamber built in. The machine can be used for approximately 20 days without resupplying the lubrication oil, assuming that the hammer is used continuously for 3-4 hours daily. Check the oil level before every use. - Page 9 1. Clean and grease the chisel shank. DO NOT lubricate the machine. 2. Pull out and rotate the stop lever 180 degrees clockwise 3. Insert chisel into the chuck clamp with the flat face of the chisel facing the stop lever. 4.
-
Page 10: Maintenance And Servicing
3. Position the tool against the surface to be hammered and pull the trigger switch. 4. For continuous use, press the trigger lock button after pressing the trigger. STOPPING WORK 1. Release the trigger or press the trigger if in continuous use mode and wait until the chisel has stopped before placing the hammer on any surface. -
Page 11: Safety Symbols
Wear Safety Glasses WEEE Directive CE Mark Class 2 Double Insulated ACCESSORIES & RELATED PRODUCTS Please contact your nearest Clarke dealer. Fully Synthetic Motor Oil Bull Point Chisel 34mm Flat Head Chisel - 5W40 • 1 litre • 30mm x 410mm •... -
Page 12: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Parts List
PARTS LIST DESCRIPTION DESCRIPTION Washer 12.5 x 18 x 0.8 Key 4 x 6.5 x 16 Washer 12.4 x 17.6 x 2.6 Nylock Hex. Socket Bolt M5 x 25 Spring 17.5 x 1.3 x 26.5 Washer Spring Case 23 x 28 Bearing Cover Pin 4 x 18 Bearing 6205... - Page 14 DESCRIPTION DESCRIPTION 61 Nylock Hex. Socket Bolt M5 x 55 Washer 62 Self Tapping Screw ST3.9 x 20 Felt Holder 63 Capacitor 0.33uF Oil Felt 7 x 70 64 Cable Plate Felt Holder Seal 65 Self Tapping Screw ST3.9 x 16 Nylock Hex.
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
