Opticon MEK-1001 Instruction Manual

Evaluation kit for series scan engines
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Evaluation Kit for MDL and MDI Series Scan Engines
Product Name
Document No.
Edition
Date of Publication
Original Doc. No.
Instruction Manual
MEK-1001
TS07004
Initial Release
July 15, 2011
TS07002
Opticon, Inc.
2220 Lind Ave. SW
Suite 100
Renton, WA 98057
www.opticonusa.com
TEL: 1.425.651.2120
FAX: 1.425.454.0865

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEK-1001 and is the answer not in the manual?

Questions and answers

Related Manuals for Opticon MEK-1001

Summary of Contents for Opticon MEK-1001

  • Page 1 Instruction Manual Evaluation Kit for MDL and MDI Series Scan Engines Product Name MEK-1001 Document No. TS07004 Edition Initial Release Date of Publication July 15, 2011 Original Doc. No. TS07002 Opticon, Inc. 2220 Lind Ave. SW Suite 100 Renton, WA 98057 www.opticonusa.com...
  • Page 2 MEK-1001 TS07004 Revision History Document Number: TS07004 Model Name: MEK-1001 Revision Date Page Description of Changes Initial 2011/7/15 (Initial Release)
  • Page 3 MEK-1001 TS07004 Note: This instruction manual provides safety and operating instructions for the MEK-1001. Please read these instructions carefully before operating this device. The information in this document has been carefully reviewed and is believed to be correct. However, no warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for use of any particular part of this document.
  • Page 4 Safety Instructions Review the following safety precautions for safe operation of the MEK-1001: Danger Do not use this device near flammable substances (such as gas and explosives).

  • Page 5: Table Of Contents

    MEK-1001 TS07004 Table of Contents ABSTRACT.......................1 OVERVIEW .......................1 HARDWARE STRUCTURE ..................1 INTERFACE SPECIFICATIONS ................1-5 BASIC INSTRUCTIONS ...................6 TROUBLESHOOTING ....................6 DETAILED VIEW.......................7 APPENDIX A: DETAILS OF THE TEST POINTS ............8 APPENDIX B: MECHANICAL DIMENSIONS OF THE MEK-1001 BOARD....8...

  • Page 6: Abstract

    2. Overview The MEK-1001 is an interface circuit board which can be used for all Opticon series scan engines. Its main functions are to start up the scan engine and to confirm the communication signals. The MEK-1001 communicates via RS-232C or USB. The MEK-1001 complies with RoHS.
  • Page 7 MEK-1001 TS07004 Table 2: CN_1 30-pin Connector Signals for MDI-1000 series (Opposite pin assignments from the ones of scan engines.) Signal Control Notes Name Function Reserved Not connected Reserved Not connected L: External light ON Controls the external light EX_ILLUMn...
  • Page 8 MEK-1001 TS07004 Table 3: CN_6 17-pin Connector Signals for MDI-23XX series (Opposite pin assignments from the ones of scan engines.) Signal Control Notes Name Function L: External light ON Controls external light EX_ILLUMn EX LED signal H: External light OFF source.
  • Page 9 MEK-1001 TS07004 Table 4: CN_5 14-pin Connector Signals for MDI-2000 series (Opposite pin assignments from the ones of scan engines.) Signal Control Notes Name Function System ground 3.3V-power supply output Not connected L: Start operation Command to start capturing TRIGn...
  • Page 10 MEK-1001 TS07004 Table 5: CN_2 12-pin Connector Signals for MDL-1000 and MDL-2000 series (Opposite pin assignments from the ones of scan engines.) Signal Control Notes Name Function L: Start operation Trigger Start operation signal H: No action (When in power down mode)

  • Page 11: Basic Instructions

    MEK-1001 TS07004 5. Basic Instructions 5-1. Scanning Operation Connect the scan engine to the appropriate scan engine connector; CN1, CN2, CN5 or CN6. Then, connect the host communication; RS-232 or USB cable to CN3. Connect the power via the AC adaptor.

  • Page 12: Detailed View

    MEK-1001 TS07004 7. Detailed View Figure 1: Detailed View of MEK-1001 POWER: Power switch to activate or deactivate the device. TRIG: Trigger switch to start the scanning operation A_WUP: Aiming and wake-up switch D_LD: Maintenance-mode switch to carry out the maintenance of a scan engine.

  • Page 13: Appendix A: Details Of The Test Points

    MEK-1001 TS07004 Appendix A: Details of the Test Points Signal Name USB+ USB- TRIGn BUZZER Appendix B: Mechanical Dimensions of the MEK-1001 Board...
