Page 1
STANDBY VOLUME/CONTRAL TUNER TONE/BAL (BAND) PHONES V I D E O TUNING CD-R/CD-RW COMPATIBLE DV-C200 DVD Receiver System DOLBY D I G I T A L V I D E O DIGITAL OUT NOTES CONTENTS 1 SAFETY INFORMATION PC board shown are viewed from parts side.
Page 2
All manuals and user guides at all-guides.com DV-C200 1 SAFETY INFORMATION SAFETY INFORMATION This product has been designed and manufactured according to FDA regulations " title 21, CFR, chapter 1,subchapter J,based on the Radiation Control for Health and Safety Act of 1968" and is classified as class 1 laser product. There is not hazardous invisible laser radiation during operation because invisible laser radiation emitted inside of this product is completely confined in the protective housings.
Page 3
All manuals and user guides at all-guides.com DV-C200 2 SPECIFICATIONS DVD Player Semiconductor laser, Wavelength 650 nm Pickup : Signal system : NTSC / PAL Audio frequency response : 4 Hz ~ 22 kHz (PCM 48kHz) 4 Hz ~ 44 kHz (PCM 96kHz)
Page 4
2. Connect the test loop antenna across the output of the signal generator. 3. Connect the oscilloscope to the speaker terminal. 4. Set the signal generator as listed in the alignment chart. T002 TC001 TC002 DV-C200 TUNER PCB T003 T105 T102 Fig. 3-1-3...
Page 5
All manuals and user guides at all-guides.com DV-C200 3-1-4 FM/AM alignment chart ITEM SG SETTING TUNER SETTING ADJUSTMENT POINT ADJUSTMENT 87.5MHz 87.5MHz Should check if the 1kHz, +/-22.5kHz dev. frequency is adjusted to 1. FM band optimal. Adjust for max.output.
Page 6
All manuals and user guides at all-guides.com DV -C200 4 EXPLODED VIEWS AND PARTS LIST EXPLODED VIEW - 1 EXPLODED VIEW - 2...
Page 7
All manuals and user guides at all-guides.com DV-C200 EXPLODED VIEW-1 REF. NO PARTS NO. DESCRIPTION REMARKS IVE100227-0001 SPONGE PAD BPH100070-0001 BRACKET IVE100226-0001 SPONGE IVE100235-0001 SPONGE IVE100235-0002 SPONGE SPEAKER DRIVER FSA040510-3310 IVE100239-0001 SPONGE GSE100221-0001 DRACKET YLB106000-0082 SPEAKER LABEL 1-10 CJS002305-0010 SPEAKER JACK...
Page 8
All manuals and user guides at all-guides.com DV-C200 EXPLODED VIEW-2 REF. NO PARTS NO. DESCRIPTION REMARKS BPC100045-0001 TOP COVER BPN100041-0001 TOP WINDOWS LENS BPH100071-0001 COVER HOLDER BPH100068-0001 HOLDER BPH100067-0001 LOADER HOLDER BPH100072-0001 SW HOLDER MICRO SWITCH MSW002005-0010 BPC100046-0001 DUST COVER...
Page 9
All manuals and user guides at all-guides.com DV -C200 EXPLODED VIEW - 3...
Page 10
All manuals and user guides at all-guides.com DV-C200 EXPLODED VIEW-3 REF. NO DESCRIPTION REMARKS PARTS NO. BPS100007-0001 SIDE PANEL (LEFT) BPL010014-0006 LOGO PLATE - SILVER BPN100047-0001 FRONT WINDOW LENS BPF104017-0001 FRONT PANEL BPK105042-0001 VOLUME KNOB BPK105041-0001 VOLUME RING BPF104016-0001 FRONT CABINET...
Page 11
All manuals and user guides at all-guides.com DV-C200 5 PC BOARDS AND PARTS LIST AMPLIFIER PCB ASSY - TOP PARTS NO. REF. NO DESCRIPTION REMARKS APE100156-0001 AMPLIFIER PCB ASSY LVM100156-0001 AMPLIFIER PCB CN601 CCH100010-0628 CONNECTOR 28PIN P=1MM FB802-804 SCB008050-6010 CHIP BEAD 600 OHM...
Page 12
All manuals and user guides at all-guides.com DV-C200 AMP PCB - TOP...
Page 13
All manuals and user guides at all-guides.com DV-C200 AMPLIFIER PCB ASSY - BOTTOM REF. NO DESCRIPTION REMARKS PARTS NO. CN301 CCN200000-0106 CONNECTOR 6PIN P=2MM CN900 CCH100060-0616 CONNECTOR 16PIN P=2MM CN901 CCN200000-0103 CONNECTOR 3PIN P=2MM C926-928,935 PVE039550-1020 CE - 25V 1000UF...
Page 14
All manuals and user guides at all-guides.com DV-C200 AMP PCB - BOTTOM...
Page 15
All manuals and user guides at all-guides.com DV-C200 MPEG PCB ASSY - TOP MPEG PCB ASSY - BOTTOM REF. NO PARTS NO. DESCRIPTION PARTS NO. DESCRIPTION REF. NO APE100157-0001 MPEG PCB ASS'Y FB202 CHIP BEAD 100 OHM SCB008050-1010 MPEG PCB...
Page 16
All manuals and user guides at all-guides.com DV-C200 MPEG PCB - TOP MPEG PCB - BOTTOM...
Page 17
All manuals and user guides at all-guides.com DV-C200 CONTROL PCB ASSY - TOP CONTROL PCB ASSY - BOTTOM PARTS NO. DESCRIPTION PARTS NO. DESCRIPTION REF. NO REF. NO APE100158-0001 CONTROL PCB ASSY FB300,301 SCB008050-6010 CHIP BEAD 600 OHM IC201 LVC100158-0001...
Page 18
All manuals and user guides at all-guides.com DV-C200 CONTROL PCB - TOP JK300 CONTROL PCB - BOTTOM...
Page 19
All manuals and user guides at all-guides.com DV-C200 TUNER PCB ASSY - TOP TUNER PCB ASSY - BOTTOM PARTS NO. DESCRIPTION REF. NO PARTS NO. DESCRIPTION REF. NO TUNER PCB ASSY RC1001837-0001 APE100160-0001 IC101 IC - LA1837 LVT100160-0001 TUNER PCB...
Page 20
All manuals and user guides at all-guides.com DV-C200 TUNER PCB - TOP EF001 TUNER PCB - BOTTOM...
Page 21
All manuals and user guides at all-guides.com DV-C200 POWER PCB ASSY OPTICAL PCB ASSY DESCRIPTION PARTS NO. DESCRIPTION REF. NO REF. NO PARTS NO. APE100155-0011 POWER PCB ASSY APE100155-0021 OPTICAL PCB ASSY LVP100155-0011 POWER PCB LVP100155-0021 OPTICAL PCB CCN250000-0113 CONNECTOR 13PIN P=2.5MM...
Page 22
All manuals and user guides at all-guides.com DV-C200 POWER PCB OPTICAL PCB...
Page 23
All manuals and user guides at all-guides.com DV-C200 6 WIRING DIAGRAM TO TUNER PCB RB101 TO MPEG PCB CN601 TO CONTROL PCB RB301 AMP PCB - BOTTOM CN601...
Page 24
All manuals and user guides at all-guides.com DV-C200 TO AMP PCB RB907 POWER PCB TO TRANSFORMER TO TRANSFORMER TO AC LINE CORD OPTICAL PCB TO DC FAN TO AMP PCB RB352...
Page 25
All manuals and user guides at all-guides.com DV-C200 MPEG PCB - TOP TO SERVO PCB J2 TO TUNER PCB RB101 CN101 CN800 CN202 CN602 TO AMP PCB RB401...
Page 26
All manuals and user guides at all-guides.com DV-C200 7 INCLUDED ACCESSORIES INCLUDED ACCESSORIES PARTS NO. DESCRIPTION REMARKS REF. NO WARRANTY CARD YWC100016-0001 YOM100138-0001 INSTRUCTION BOOK AM LOOP ANTENNA VTA100001-0020 FM ANTENNA VTA400001-0020 VWS331044-2000 SPEAKER CABLE x 2 FBY064015-0003 BATTERIES (AAA,R03, UM-4) x2...
Page 27
TEAC NEDERLAND BV Oeverkruid 15,NL-4941 W Raamsdonksveer, Nederland Phone:0162-510210 TEAC BELGIUM NV/SA. c/o TEAC NEDERLAND BV, Oeverkruid 15, NL-4941 W Raamsdonksveer, Nederland Phone:+31-162-510860 TEAC ITALIANA S.p.A. Via C, Cantu 11, 20092 Cinisello Balsamo, Milano, Italy Phone:02-66010550 TEAC AUSTRALIA PTY., LTD.
Page 28
T1.6A L 250V 2PIN2.5 R914 CN352 R913 R354 JK353 F903 T3.15A L 250V R355 100 C380 F909 T3.15A L 250V C381 CON5 100UF CN977 F908 T3.15A L 250V GPIF32T OPTICAL BOARD C977 1KV 103 DV-C200 CN908 RB909 DVD Receiver System...
Page 29
DD11 HD11 OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN RL212 33x4 R267 R268 R269 R270 R271 R272 R273 R274 R275 R276 R277 R278 DD12 HD12 DD13 HD13 DD14 HD14 DD15 HD15 DV-C200 DVD Receiver System...
