Contents Safety notes ................... 1 Specifications ..................2 Switchig on and weighing ..............2 Counting function ................. 3 Determining individual weights with the balance ............... 3 Determine individual weight via keyboard ................. 3 Quantity check function ............... 3 Specify number of pieces as target quantity ..............3 Checking the piece quantity - check function with alarm ...........
Safety notes Please read this quick start guide carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the guide are excluded from our liability and not covered by our warranty.
Specifications Weighing plate 1 Measurement range 25 kg / 55 lbs Measurement accuracy ±2 g Resolution 0.5 g Weighing plate dimensions 345 x 260 mm / 13.6 x 10.2 in Weighing plate 2 Measurement range 1 kg / 2.2 lbs Measurement accuracy ±0.08 g Resolution...
Counting function Determining individual weights with the balance - Place any quantity of pieces on the balance as a reference. - Enter the number of pieces via the keyboard. - Press the SAMPLE key. - under UNIT WEIGHT, the determined individual weight is displayed a) Count immediately with this single weight - Remove reference quantity - Place container on platform and tare with >T<...
Back to normal piece counting - The check function must be set to CH=OFF. - Press key; switch to CH=OFF with ENTER. - Return to normal weighing mode with key. Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms.
