The WS 12000 Unit needs preventative maintenance every year.
Follow the instructions below for appropriate instructions.
Part 1: Sanitizing the Unit
You will need:
Phillips head screw driver
TDS meter
Microfiber towels & paper towels
Gloves
5 gallon bucket
Thermometer
Tubing & tube cutters
Pledge multi-surface
Hydrogen Peroxide
Step 1: Remove all 9 screws circled
above. Then remove the top & rear
panel.
Step 3: Peel back insulation to
expose the 'ice making' sensor and
the 'ice full' sensor receive.
Step 5: Remove
the two screws located on the
holding tank, just behind the panel.
Pre-Sediment Filter (ICESEO): 1 year or 2500 gallons max
Pre-Carbon Filter (ICEPREC): 1 year or 2500 gallons max
Reverse Osmosis (ICERO): 3 years or 4500 gallons max
TCR Filter (ICEPOSTCA): 3 years or 2500 gallons max
Step 2: Remove the two screws
indicated above and remove the
everything from the upper front half
remove the Styrofoam bin lid.
front panel.
Step 4: Remove
of the holding tank.
Step 6: Carefully
Advertisement
Table of Contents
Related Manuals for Wellsys WS 12000
Summary of Contents for Wellsys WS 12000
- Page 1 The WS 12000 Unit needs preventative maintenance every year. Follow the instructions below for appropriate instructions. Part 1: Sanitizing the Unit You will need: Phillips head screw driver TDS meter Microfiber towels & paper towels Gloves 5 gallon bucket Thermometer Tubing &...
- Page 2 Step 8: Slide the ice tray out of the Step 7: Remove the screws unit. Step 9: Remove the screws Step 10: Remove grid from the unit. Step 11: Remove the screws Step 12: Gently lift and remove the evaporator out of the way for easier cleaning.
- Page 3 Step 16: Liberally spray the solution Step 17: Slide clips into open on the parts you removed and rinse position and remove the four in a sink screws in the top corners of the ambient tank to gain access inside. Step 18: Liberally spray the inside of the ambient tank and rinse in a sink.
- Page 4 Part 2: Filter Replacement You will need: Filter Change Regime: Phillips head screw driver Pre-Sediment Filter: 1 year or 2500 gallons max TDS meter Pre-Carbon Filter: 1 year or 2500 gallons max Microfiber towels & paper towels Reverse Osmosis: 3 years or 4500 gallons max Gloves Ultra Fine: 3 years or 4500 gallons max 5 gallon bucket...
