Summary of Contents for argon audio ONE PI 4 V2
- Page 2 ARGON ONE PI 4 V2 PARTS Magnetic Removable Top Cover 40 Pin GPIO Access USB�C Power In 2 x USB 2.0 2 x USB 3.0 SD Card Slot Power Button Audio Out Gigabit Ethernet 2 x Full HDMI www.argon40.com...
- Page 3 Connect Raspberry Pi to HDMI�Audio Board and stick Silicon Thermal Pads. *push all the way in the HDMI DAUGHTERBOARD SILICON THERMAL PAD Reminder: Peel off plastic on both sides of the thermal pad ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 4 Carefully connect Raspberry Pi GPIO to Power and Cooling Board. Press POWER ON button to start. Please make sure that the microSD Card is NOT inserted to the Raspberry Pi during assembly. www.argon40.com...
- Page 5 Use shorter flat head screws to fasten Raspberry Pi and HDMI Board assembly to top case. ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 6 Select the Argon ONE Power Button Management Mode: JUMPER PIN MODE BEHAVIOUR SETTING Default Set- You need to PRESS button to Pin 1�2 ting Power ON from shutdown or �Mode 1� power outage. Power current will flow directly Always ON to Raspberry Pi.
- Page 7 ARGON ONE PI 4 V2 JUMPER PIN SETTING ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 8 Use longer round head screws to fasten bottom cover and place rubber footings. www.argon40.com...
- Page 9 Insert SD Card in SD Card slot. Plug HDMI and Power Supply. Don’t forget to PRESS Power Button to TURN ON MINIMUM POWER REQUIREMENT� 5 Volt, 3 Amp (5V 3A� ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 10 HOW TO INSTALL ARGON ONE PI 4 V2 POWER BUTTON & FAN CONTROL Maker Coding Alert 1. Connect to the internet. 2. Open “Terminal” in Raspbian. 3. Type the text below in the “Terminal” to initiate installationof Argon ONE Pi 4 script.
- Page 11 ARGON ONE Pi 4 ACTION FUNCTION STATE Short Press Turn ON Soft Shutdown Long Press (>= 3 s) and Power Cut Short press (<3 s) Nothing Double tap Reboot Forced Long Press (>= 5 s) Shutdown ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 12 ARGON ONE PI 4 V2 FAN SPEED Upon installation of the Argon ONE Pi 4 script by default, the settings of the Argon ONE Pi 4 cooling system are as follows: Coding CPU TEMP FAN POWER 55 C Maker 60 C...
- Page 13 Argon ONE Pi 4 Uninstall icon on your Desktop. You may also remove the script via “Terminal” by typing: argonone-uninstall Always reboot after changing any configuration or uninstallation for the revised settings to take effect. ARGON ONE PI 4 V2 INSTRUCTION MANUAL...
- Page 14 BUILT�IN INFRARED RECEIVER The latest version has a programmable Infrared Receiver installed that can turn ON and OFF the device using the proprietary Argon 40 remote. To configure the Infrared Receiver ON/OFF signal of Argon ONE V2 and M.2 type in the Terminal App: argonone-ir Then follow the instructions indicated.
