- Page 1 VICTORIA PLUS SILENT MANUAL SWIMMING POOL PUMPS V I C T O R I A P L U S S I L E N T...
-
Page 2: General Safety Instructions
IMPORTANT This manual contains basic information on the safety measures to be adopted during installation and start-up. The fitter and the user must therefore read the instructions before installation and start-up. The manual can be downloaded as a PDF file from the website: www.astralpool.com 1. - Page 3 WARNINGS DURING INSTALLATION AND ASSEMBLY WORK - In cases of junction box connections only: when connecting the electrical wiring to the mo- tor, check the layout inside the connection box and make sure there are no pieces of wiring inside after it has been closed and that the earthing conductor is correctly connected. Con- nect the motor in line with the wiring diagram attached to the machine.
- Page 4 - Follow the steps below before handling the unit: 1. Disconnect the unit from the mains. 2. Block all start-up devices. 3. Check that there is no voltage in the circuits, even in the auxiliary circuits and additional features. 4. Wait for the impeller to come to a complete standstill. The above list is a guideline only as there may be other requirements in addition to local laws for safety reasons.
- Page 5 3. INSTALLATION AND ASSEMBLY GENERAL - Our pumps may only be assembled and installed in pools or ponds that are compliant with stan- dard HD 384.7.702. Should you have any doubts, please consult your dealer. - The installation should follow standard IEC 60364-7-702 for swimming pools. - The pump can be installed in zones 1 or 2.
-
Page 6: Electrical Installation
ELECTRICAL INSTALLATION - It is essential that you use a multiple disconnection device with a space of at least 3 mm between surfaces to disconnect the unit from the electrical current. - Use a rigid cable to connect the pump to the mains. If you use a flexible cable to connect it to the mains, it must have cable lugs to connect it to the terminals of the pump’s motor. -
Page 7: Maintenance
4. START-UP INSTRUCTIONS PRIOR TO START-UP - Measurements prior to first start-up: 1. Remove the pre-filter cap by unscrewing the nut holding it in place (Fig. 5). 2. Fill the pump with water through the pre-filter until it rises up through the suction pipe. 3. - Page 8 - Pump components that, due to their normal use, suffer wear and/or tear must be regularly repla- ced to ensure good pump performance. The following table lists the fungible and / or consumable components of the pump and the period of time in which they must have been replaced. DESCRIPTION OF THE COMPONENT TIME BETWEEN REPLACEMENTS 10,000 h...
-
Page 9: Troubleshooting
7. TROUBLESHOOTING The pump will not start The pump is not primed The motor is making a noise but will not start The pump only releases a small flow of water The motor has stopped The pump makes a noise 1 2 3 4 5 6 CAUSES SOLUTIONS... - Page 10 ANCHOR DETAIL Anchor detail Fig. 1 CORRECT INCORRECT Union Union Gasket / Joint Gasket / Joint Union Union Fig. 2...
- Page 11 Priming Fig. 3 Pump Fig. 4...
- Page 12 Pre-filter cover nut Pre-filter cover Tower joint Seatin joint to be cleaned Pre-filter Basket Fig. 5 Fan Cover CORRECT INCORRECT Fig. 6...
-
Page 13: Three Phase Motors
SINGLE PHASE MOTORS Condensor THREE PHASE MOTORS SINGLE PHASE THREE PHASE Fig. 6... -
Page 14: Guarantee Certificate
3.3. The guarantee does not cover accessory elements of the product “Victoria Plus Silent” not explicitly included on it, such as panel board, converter, protection devices, etc. - Page 15 ASTRAL VICTORIA PLUS SILENT PUMP SPECIFICATIONS - PRODUCT AND ACCESSORIES DESCRIPTION ENGLISH The body of the pump is made of the latest generation thermoplastics. The pumps are self-priming and range from 0.50 HP up to 3 HP, and are provided with both single-phase and three-phase motors. A pre-filter has been integrated into the body of the pump to prevent the entry of any foreign bodies which could cause damage to the hydraulic parts of the pump.
-
Page 17: Technical Characteristics
TECHNICAL CHARACTERISTICS MOTOR NOISE DIMENSIONS (mm) VOLTAGE max. PIPE CODE 65557 0,58 581 281 246 ACME D.75 2" GAS 359 322 321 164 254 ½ 65558 0,55 230 - 400 581 281 246 ACME D.75 2" GAS 359 322 321 164 254 65560 0,65 581 281 246 ACME D.75 2"...
