- Page 1 CGM System Quick Start Guide (mmol/L)
-
Page 2: Table Of Contents
Contents Overview Register and Login Mobile Settings EasySense Settings Glucose Alerts Settings Apply Sensor Warm-up and Calibration Read CGM CGM Alerts Remove Sensor Your Personal Settings Medtrum Simplifying Diabetes... -
Page 3: Overview
• The Sensor (with Transmitter snapped in) is waterproof at 8 feet (2.5 meters) for 60 minutes (IPX8). • Store the Sensor at temperatures between 2°C (36°F) and 30°C (86°F). • Store the Transmitter at temperatures between -10°C (14°F) and 55°C (131°F). Medtrum Simplifying Diabetes... -
Page 4: Register And Login
• Enter the verification code, your full name and password. • Read and agree to the privacy policy and terms of use, tick the small boxes and tap Create Account to register your Medtrum Account. 3. Login • Tap the national flag on the top right corner and select the country you chose upon registration, and then log in with your account and password. -
Page 5: Mobile Settings
Make sure you allow the App to access the device’s location so that the App can use the Bluetooth feature. • Make sure the EasySense App is locked in the background. • Open auto run in the smart manage (Samsung). • Medtrum Simplifying Diabetes... -
Page 6: Easysense Settings
Tap Add Transmitter and add Transmitter SN by 2. Set Alert tones/Unit settings entering SN manually or scanning QR code. Main Menu ➔ Settings ➔ General Settings➔ Alert Tones/Unit Settings The Glucose unit is fixed, depending on your App version. Medtrum Simplifying Diabetes... -
Page 7: Glucose Alerts Settings
Glucose Alerts Settings Main Menu ➔ CGM System ➔ Glucose Alerts Predictive Alerts High/Low Alerts • You will be reminded of a predicted high or low • You will be reminded when your glucose is above glucose value some time (the predictive alert time) -
Page 8: Apply Sensor
Place the Sensor and move Squeeze the two release Remove the two pieces of your fingers around the tabs and remove the safety protective liners. adhesive pad, apply pressure lock from the inserter. to the top of the inserter. Medtrum Simplifying Diabetes... - Page 9 • Put in the round part of the Transmitter first • Snap the Transmitter into the Sensor support mount • The indicator light will flash green 3 times first then another 6 times within one minute Note: Repetitive disconnecting and reconnecting may damage the sensor Medtrum Simplifying Diabetes...
-
Page 10: Warm-Up And Calibration
• The sensor need to be calibrated twice (once every 12 hours) on the first day and then once every 24 hours since the second day. • Tap the calibration icon on Monitor Screen, enter BG and confirm the value. Medtrum Simplifying Diabetes... -
Page 11: Read Cgm
Read CGM Home Screen Sensor Status Trend Arrow Calibration lcon Last Sensor Reading Sensor Condition Time of the Reading Remaining Sensor Life Sensor Condition • Not Calibrated : the sensor has not been calibrated after warm • Monitoring : the sensor and transmitter are both working properly, and the transmitter is sending the sensor glucose data to the app. - Page 12 Read CGM Landscape View Double tap the Sensor Trend Graph or hold your smart device horizontally Main Menu Statistics Detailed Glucose at the top-left Information corner to open the Main Menu ➔ Statistics Main Menu Tap the Sensor Status Slide the screen to view four...
-
Page 13: Cgm Alerts
CGM Alerts Alerts Examples App Messages Actions to Take Alerts: Move your smart device Alerts are trigged by conditions that may LOST SENSOR close to the Transmitter. require your attention. Do not ignore the Alerts. Enter a new meter BG for... -
Page 14: Remove Sensor
• If the Sensor Expiration alerts are on, each sensor session will end automatically after 14 days. After that, you can remove the sensor from your body. • Make sure the Transmitter was disconnected from the old Sensor over 90 seconds before it is connected to a new one. Medtrum Simplifying Diabetes... -
Page 15: Your Personal Settings
Type Status / Time High Glucose Limits (mmol/L) Start Time Low Limit High Limit Rate Alerts (mmol/L/min ： Type Status / Rate ： Rise ： Fall ： Snooze ： ： Type Status / Repeat ： High ： Medtrum Simplifying Diabetes... - Page 16 Medtrum Technologies Inc. 7F, Building 8, No. 200, Niudun Road Shanghai 201203, China Tel: +86-21-50274781 Fax: +86-21-50274779 Medtrum B.V. Nijverheidsweg 17 EC REP 5683 CJ Best The Netherlands Tel: +31 (0) 499745037 This product complies with Directive 93/42/EEC (MDD) and Directive 0197 2014/53/EU (RED).
