- Page 1 INSTALLATION MANUAL Packaged water-cooled water chillers EWWP045KAW1M EWWP055KAW1M EWWP065KAW1M ECB2MUAW ECB3MUAW...
- Page 2 3PW61842-5...
-
Page 3: Electrical Specifications
The units are available in 11 standard sizes with nominal cooling capacities ranging from 86 to 195 kW. The EWWP units can be combined with Daikin fan coil units or air handling units for air conditioning purposes. They can also be used for supplying chilled water for process cooling. - Page 4 PERATION RANGE NPACKING AND PLACING THE UNIT Cut the straps and remove the cardboard box from the unit. Remove the four screws fixing the unit to the pallet. Level the unit in both directions with the lifting lugs which are delivered with the control box (ECB*MUAW).
- Page 5 ATER QUALITY SPECIFICATIONS NOTE Provide adequate safeguards in the water circuit to make sure that the water pressure will never exceed the maximum allowable working pressure. evaporator water condenser water circulating circulating tendency water supply water supply if out of [<20°C] water [20°C~60°C]...
-
Page 6: Interconnection Cables
Connection of the water-cooled water chiller power EFORE STARTING supply The unit should not be started, not even for a very short Using the appropriate cable, connect the power circuit to the N, period of time, before the following pre-commissioning L1, L2 and L3 terminals of the unit. -
Page 7: Startup And Shutdown
..................................................................Phone Phone : ..................: ....................QUIPMENT TECHNICAL DATA Manufacturer : DAIKIN EUROPE ....Power supply (V/Ph/Hz/A) : ......... Model : ..........Maximum high pressure : .......31 bar Serial Number : ..........Charging weight (kg) R407C : ......... - Page 9 NNEX Installing the control box 2 - 3 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 10 2 - 3 - 4 EWWP045~065KAW1M + ECB2+3MUAW Packaged water-cooled water chillers Installation manual Annex 4PW61663-1A – 2012.04...
- Page 11 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 12 EWWP045~065KAW1M + ECB2+3MUAW Packaged water-cooled water chillers Installation manual Annex 4PW61663-1A – 2012.04...
- Page 13 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 14 EWWP045~065KAW1M + ECB2+3MUAW Packaged water-cooled water chillers Installation manual Annex 4PW61663-1A – 2012.04...
- Page 15 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 16 EWWP045~065KAW1M + ECB2+3MUAW Packaged water-cooled water chillers Installation manual Annex 4PW61663-1A – 2012.04...
- Page 17 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 18 50 Hz ~ 3 x 400 V + EWWP045~065KAW1M + ECB2+3MUAW Packaged water-cooled water chillers Installation manual Annex 4PW61663-1A – 2012.04...
- Page 19 Packaged water-cooled water chillers EWWP045~065KAW1M + ECB2+3MUAW Installation manual Annex 4PW61663-1A – 2012.04...
- Page 20 4PW61663-1A 2012.04...
