Chauvet Q-Roll 250 Supplementary Manual

DMX Channel Values (16 Bit)

D
EFAULT
1
2
3
4
5
6
7
Q-Scan 250 & Q-Roll 250 User Manual
V
ALUE

Pan

000 255 Left > Right ( 128 = center)

Tilt (Q-Scan 250)

000 255 Up > Down (128 = center)

Barrel Spin (Q-Roll 250)

000 005 Stop
006 120 Rotation: Fast > Slow (clockwise)
121 140 Stop
141 255 Rotation: Slow > Fast (counter-clockwise)

Shutter/Strobe/Dimmer

000 005 Blackout
006 063 Dimmer: Closed > Open (0-100%)
064 095 Variable strobe: Slow > Fast
096 127 Open
128 159 (no function)
160 191 Pulse strobe in sequence: Slow > Fast | (Close > Open)
192 223 Pulse strobe in sequence: Fast > Slow | (Open > Close)
224 255 Open

Rotating Gobo Wheel

000 013 Open
014 027 Gobo 1
028 041 Gobo 2
042 055 Gobo 3
056 069 Gobo 4
070 083 Gobo 5
084 097 Gobo 6
098 111 Gobo 7
112 126 Gobo 8
127 136 Open
137 146 Gobo 1 (variable bounce): Slow > Fast
147 156 Gobo 2 (variable bounce): Slow > Fast
157 166 Gobo 3 (variable bounce): Slow > Fast
167 176 Gobo 4 (variable bounce): Slow > Fast
177 186 Gobo 5 (variable bounce): Slow > Fast
187 196 Gobo 6 (variable bounce): Slow > Fast
197 206 Gobo 7 (variable bounce): Slow > Fast
207 217 Gobo 8 (variable bounce): Slow > Fast
218 219 Open
220 255 Gobo spin: Slow > Fast

Color Wheel

000 009 White (Open)
010 020 Red
021 031 Blue
032 041 Yellow
042 052 Light Green
053 063 Magenta
064 073 UV
074 084 Light Blue or Cyan
085 095 Orange
096 105 Pink
106 116 Tri-color: Red – White - Blue
117 128 Quad-color: Blue – Pink – Purple - Yellow
129 190 Linear progression of color wheel (color-splits)
191 220 Rainbow effect: Fast > Slow (clockwise)
221 222 Stop
223 255 Rainbow effect: Slow > Fast (counter-clockwise)

Gobo Rotation

000 127 Gobo incremental rotation
128 189 Clockwise gobo rotation: Fast > Slow
190 193 No Rotation
194 255 Counter clockwise gobo rotation: Slow > Fast

Pan/Tilt Speed (P7-n setting)

000 000 Tracking control: Maximum
001 200 Vector control: Maximum > Slowest
201 204 Fixture Reset (hold 3 to 5 seconds)
205 255 Tracking control: Maximum
14
F
UNCTION
Appendix
2007-03-12/15:24
